AMF Thermatex Acoustic Ceiling Tile
Description

AMF Thermatex Acoustic is a 19 mm thick suspended ceiling tile made from a specially perforated mineral board and an acoustic fleece facing. The perforations provide excellent sound absorption while the fleece offers a smooth, elegant surface finish.

The combination of high density, bio-soluble mineral wool with clay and starch provides excellent physical characteristics, particularly for acoustic performance. The AMF Acoustic Range carries the Declare label.

Key Features
  • Two-way exposed Grid System, demountable ceiling
  • Free span system, with exposed or concealed suspension
  • Bandraster system, with exposed or concealed suspension
  • Dimensions: 600 x 600mm, 625 x 625mm, 1200 x 600mm
  • Thickness / Weight: 19mm (c. 5.0 kg/m²)
  • Colour: White similar to RAL 9010
  • Edge details: SK, VT 15/24 on request, AW, GN
Declare LBC Red List Free
Declare LBC Red List Free
Scope of Use
  • Exposed grid system, demountable ceiling
  • Free span system, with exposed or concealed suspension
  • Bandraster system, with exposed or concealed suspension
  • Concealed system, panels demountable / non demountable
Other Performance Attributes
  • Sound absorption: αw = 0.65H as per EN ISO 11654.
  • NRC = 0.70 as per ASTM C 423-01
  • Sound attenuation: Dn,c,w = 39 dB as per EN 20140-9 (19 mm thickness). Dn,c,w = 40 dB as per EN 20140-9 (semi-concealed planks)
  • Light reflectance: up to 88%
  • Thermal conductivity λ = 0.052 – 0.057 W/mK as per DIN 52612
  • Humidity: up to 95 % RH
  • Clean room: Class 3 as per ISO 14644-1
Documents
Data Sheet: AMF Thermatex Acoustic
