Description

Alucolux is a 3mm solid, coil coated aluminium sheet material for exterior cladding and interior linings. Developed from the optimum marine grade aluminium, Alucolux is the perfect combination of temper and hardness. Architectural cladding applications require the correct combination of these properties to perform when exposed to wind loads and pressure.

Alucolux provides a non-combustible cladding solution for compliance and safety with no complications. Deemed non-combustible and certified to EN 13501-1.

Alucolux is available in most of the same colours found in the Alucobond Plus range and is also available in embossed surfaces to liven up the Wood Look and Stone Look ranges.

Key Features

100% Non-combustible to EN 13501-1
Guaranteed Premium PVDF finish
3mm solid non-combustible aluminium
Coil coated for colour consistency
Surfaces can be textured
1575mm wide sheet size up to 6000mm long can be provided

Ranges

Cladding

Scope of Use

Alucolux provides a non-combustible cladding solution:

Exterior cladding
Interior linings

Alucolux can offer embossed surfaces, 3-D shapes, perforations, and textured finishes

Typical applications:

High rise buildings
Industrial buildings
Public buildings
Tunnels, stations, subway stations
Airports
Hotels, hospitals, shopping malls
Stadiums, event centres and halls

Limitations on Use

These panels may only be used in conjunction with a tested and proven system
SYMONITE has on offer three separate systems to cater to most construction needs, should needs fall outside of these systems scope; testing and compliance of system will need to be proven.
Applicable and tested systems available are Rout & Return, Hook & Pin and WAB

Statement of Building Code Compliance

When paired with a tested and compliant system this cladding material will perform in accordance with all applicable NZBC Clauses
Clause C — Protection from Fire: Alucolux is deemed non-combustible and certified to EN 13501-1

In-Service History

Alucolux has been on offer and development by 3A since 1962.

Other Performance Attributes

Developed from marine grade aluminium
PVDF paint system — paint will not crack when folded, offers remarkable colour consistency
Product is fully recyclable
Guarantee is standard 15 years
