Equitone: HD Fibre Cement Cladding

In Symonite's quest to offer the world’s best architectural facades systems they've now developed a number of Equitone High Density Façade fixing systems to ensure they can deliver cost-effective, high performing buildings for residential and commercial use to start off the new year. And now they have CodeMark.

Symonite’s technical department develops solutions that cope with the most diverse applications such as exterior and interior cladding, sun protection, modular systems and balconies. Specifically developed and tested T50 cavity system with the option to add exterior insulation

Equitone fibre cement facade material has 'smashed' the extreme B58414 full scale wall assembly test. The B58414 test evaluates whether a cladding system that is subjected to a fire breaking out of an opening in an external wall will result in excessive fire spread up the outside of the building — creating a risk of the blaze re-entering the building at a higher level.

Equitone — Fibre Cement Cladding

Symonite

View Product

A durable and contemporary option for exterior cladding; Every Equitone panel is a unique cement composite material that consists of cement, cellulose and mineral materials, reinforced by a visible matrix.

Specifically developed and tested 50mm cavity system
Glue (concealed) fix or visible stainless-steel fixings

When working with the T50 System:

Suitable for use on multi-level residential and commercial interior and exterior facades
Fixed over Serge Ferrari Stamisol Building Textile or selected Rigid Air Barrier systems compliant with Table 23 of NZBC/E2:2011
Approved and tested for use on buildings with factored wind loads up to 3.0 kPa. For higher wind loads a site-specific approval will be required
Suitable for use in all environments, including sea spray zones
Panel sizes may be restricted depending on the cladding product specified, contact Symonite for more information

Fire safe — non-combustible and no spread of flame
The products have been tested according to NZS2908 and have been used all over the world and in the most diverse climate zones
Resistant to extreme weather conditions and temperatures
Integral 'through-colour' — no ongoing maintenance required
Installed life expectancy of at least 50 years
Resistant to vermin, insects, mould growth, fungi etc
