JSC installation and specification guide and CodeMark certificate guidelines must be followed.

JSC RustiClad — Rusticated Horizontal Weatherboard Cladding System – CodeMark Certificate: CMNZ30081

Location

• In wind zones up to and including extra high, as defined in NZS3604:2011 or situated in specific design wind pressures up to a maximum design differential ultimate limit state (ULS) of 2.5 kPa, where the building has been specifically engineered
• In all exposure zones, excluding microclimates as defined in NZS3604:2011

Building

• Has the scope limitations of NZBC Acceptable Solution E2/AS1, Third Edition including amendment 10 (5 November 2020), Paragraph 1.1; and,
• New timber framed buildings with building wrap or rigid air barrier that comply with the NZBC Acceptable Solution E2/AS1 Third Edition including amendment 10 (5 November 2020),
• Existing timber framed buildings where the designer and installer have satisfied themselves that the existing building is suitable for the intended building work
• With a risk score of 0-20 when calculated in accordance with NZBC Acceptable Solution E2/AS1, Third Edition including amendment 10 (5 November 2020), Table 2
• The System must only be installed horizontally on vertical, flat, surfaces
• The System is certified for use with aluminium window and door joinery that is installed with vertical jambs and horizontal heads and sills
• The wall cladding system is located more than 1m from a relevant boundary.

Note: See CodeMark Certificate for full and up to date information. Please refer to installation instructions and maintenance guide available for download under Documents.

JSC weatherboard cladding must be used as an external cladding system within the scope and limitations of JSC Cladding Systems technical literature. All weatherboard and timber components must be installed, maintained, and finished as per the JSC specification.

It is the specifier's responsibility to ensure that the details in this specification are appropriate for the intended application. Additional details must be obtained for areas that fall outside the scope of the JSC RustiClad weatherboard cladding system technical literature and CodeMark certificate.

For the fixing of JSC TMT thermally modified timber weatherboards, only Stainless Steel fastenings must be used.

JSC Cladding systems must be installed by a suitably qualified and experienced trade person. Where Restricted Building Work (RBW) is applied the installer must be a Licensed Building Practitioner (LBP) or supervised by an LBP.

The JSC Weatherboard Systems if designed and installed as per the JSC RustiClad installation and specifications guide, will meet the following provisions of the New Zealand Building Code (NZBC):

• Clause B1 STRUCTURE: Performance B1.3.1, B1.3.2, B1.3.4 for the relevant physical conditions of B1.3.3 (a), (h), (j) and (q).
• Clause B2 DURABILITY: Performance B2.3.1(b) and B2.3.2(b).
• Clause E2 EXTERNAL MOISTURE: Performance E2.3.2, E2.3.5, E2.3.7.
• Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1.

JSC Western Red Cedar Weatherboard System, if installed and maintained as per manufacturer’s documentation, will meet the minimum 15-year durability requirement in respect of clauses B1 and B2 of the first schedule of the New Zealand Building Code for external cladding. In a typical installation, it is likely to have a serviceable life exceeding 30 years.

• All suitable timber product offerings will eventually weather to shades of grey when subjected to the environmental elements of temperature, moisture, and UV rays. Therefore, to help maintain the fresh, new colour, the use of a premium grade oil stain with a UV protectant is recommended, with a factory-applied envelope coat as the first step to a long and beautiful life.
• All JSC Timber weatherboards are finished with high-quality exterior grade coating options.
• JSC weatherboards are available in a range of timber product offerings and manufactured to JSC specifications and designed in accordance with NZS3617 and BRANZ BU411
• H3.2 treated timber castellated cavity battens are used
• Quality Flashings and accessories are used
