• FBL-100 has been tested as per NZBC C/AS2 -C/AS6 Appendix C, for interior use only, as part of a providing a 'Fire Resistance Rating' (FRR) of up to 60/60/60 on either:
  • Timber (or better) framed walls exposed to fire from either or both sides (two-way FRR), or exposed to fire from the coated side (one way FRR)
  • Timber framed (or better) floor/ceiling systems exposed to fire from below in residential, commercial or industrial buildings on 13mm Standard Plasterboard
• FBL-100 has been tested as per NZBC C/VM2 Appendix A and can be used to prevent spread of fire on interior wall or ceiling substrates. It achieves Group 2-S on Type 1 (most reactive) as per C/VM2 A1.6, Table A2
• FBL-100 can be applied over existing pre-painted surfaces
• FBL-100 can be applied on new or existing substrates, subject to fixing pattern (refer to TCNZ for further instruction)
• FBL-100 can be applied to structural timber works and can also be used to protect internal load bearing wood from fire, therefore reducing cross-sectional area requirements, or omitting the use of encapsulating board
• For the purpose of defining the 'Level of finish' for pre-application of FBL-100
  • The surface that is to be coated must be finished to minimum Level 4, (AS/NZS 2589)
• For the purpose of defining the 'Level of Finish' for post-application of FBL-100
  • Once FBL-100 has been applied, it achieves an indicative Level 4 for walls and ceilings, although the finish level will be as per the sample provided by the 'TCNZ Certified Applicator'
• FBL-100 has been tested to be used on building materials and building practices used in projects designed and built on and after 1995
• For the purpose of defining the classification of 'Interior Environments' that FBL-100 may be used in, is as per AS/NZS 2311.1 — Section 2, Table 2.1:
  • FBL-100 may be used in Category C1 (Very Low) and C2 (Low) environments

• Timber (or better) framed walls exposed to fire from either or both sides (two-way FRR), or exposed to fire from the coated side (one way FRR)
• Timber framed (or better) floor/ceiling systems exposed to fire from below in residential, commercial or industrial buildings on 13mm Standard Plasterboard

• The surface that is to be coated must be finished to minimum Level 4, (AS/NZS 2589)

• Once FBL-100 has been applied, it achieves an indicative Level 4 for walls and ceilings, although the finish level will be as per the sample provided by the 'TCNZ Certified Applicator'

• FBL-100 may be used in Category C1 (Very Low) and C2 (Low) environments

Show more

• B2.3.1 Performance — Building elements must, with only normal maintenance, continue to satisfy the performance requirements of this code for the lesser of the specified intended life of the building, if stated, or (c) 5 years if:
  • (i) The building elements (including services, linings, renewable protective coatings, and fixtures) are easy to access and replace, and
  • (ii) Failure of those building elements to comply with the building code would be easily detected during normal use of the building

• (i) The building elements (including services, linings, renewable protective coatings, and fixtures) are easy to access and replace, and
• (ii) Failure of those building elements to comply with the building code would be easily detected during normal use of the building

• FBL-100 has been tested and assessed to:
  • AS 1530.4:2014 — Methods for fire tests on building materials, components and structures: Fire resistance tests for elements of construction; and
  • ISO 9705:1993 — Fire Test: Full-scale room test for surface products
• As per the following:
  • Appendix C (normative) Test Methods of any of the NZBC – C/Acceptable Solutions (C/AS2 — C/AS6)
  • Appendix A (normative): Establishing Group Numbers for lining materials of NZBC – C/Verification Method Two (C/VM2)
• Therefore, is able to be used where the New Zealand Building code calls for a Fire Resistance Rating (FRR) or where a Group 2-S or better Interior Lining is needed

• AS 1530.4:2014 — Methods for fire tests on building materials, components and structures: Fire resistance tests for elements of construction; and
• ISO 9705:1993 — Fire Test: Full-scale room test for surface products

• Appendix C (normative) Test Methods of any of the NZBC – C/Acceptable Solutions (C/AS2 — C/AS6)
• Appendix A (normative): Establishing Group Numbers for lining materials of NZBC – C/Verification Method Two (C/VM2)

• FBL-100 has been designed to achieve a NZBC Group Number for surface finishes as per Appendix A of NZBC C/VM2.FBL-100 has been tested and assessed to achieve a Group 2-S on Type 1 substrates or better as per Appendix A1.6 Table A2 of NZBC C/VM2

All relevant certificates, assessments and reports are available upon request.

Show more

Independent Assessment

Test Results

• FBL-100 has been tested as per NZBC C/AS2 -C/AS6 Appendix C, for interior use only, as part of a providing a 'Fire Resistance Rating' (FRR) of 60/60/60 on either
• Timber (or better) framed walls exposed to fire from either or both sides (two-way FRR), or exposed to fire from the coated side (one way FRR) and
• Timber framed (or better) floor/ceiling systems exposed to fire from below in residential, commercial or industrial buildings on the following substrates:
• 13mm GIB Standard Plasterboard,
• 6mm fibre cement sheet,
• 12mm plywood
• Exposed timber floors/ceilings (underside only)
• FBL-100 has been tested as per NZBC C/VM2 Appendix A and can be used to prevent spread of fire on interior wall or ceiling substrates. It achieves Group 2-S on Type 1 (most reactive) as per C/VM2 A1.6, Table A2
• FBL-100 can be applied over existing pre-painted surfaces
• FBL-100 Can be applied on new or existing substrates, subject to fixing pattern (refer to: Appendix A, Table 1, Substrate Fixing).
• FBL-100 can be applied to structural timber works and can also be used to protect internal load bearing wood from fire, therefore reducing cross-sectional area requirements, or omitting the use of encapsulating boards.
• For the purpose of defining the 'Level of finish' for pre-application of FBL-100 —
• The surface that is to be coated must be finished to Level 4, minimum (AS/NZS 2589)
• For the purpose of defining the 'Level of Finish' for post-application of FBL-100 —
• Once FBL-100 has been applied, it achieves an indicative Level 4 for walls and ceilings, although the finish level will be as per the sample provided by the 'TCNZ Certified Applicator'
• FBL-100 has been tested to be used on building materials and building practices used in projects designed and built on and after 1995
• For the purpose of defining the Classification of 'Interior Environments' that FBL-100 may be used in, is as per AS/NZS 2311.1 — Section 2, Table 2.1:
• FBL-100 may be used in Category C1 (Very Low) and C2 (Low) environments

• Timber (or better) framed walls exposed to fire from either or both sides (two-way FRR), or exposed to fire from the coated side (one way FRR) and
• Timber framed (or better) floor/ceiling systems exposed to fire from below in residential, commercial or industrial buildings on the following substrates:
• 13mm GIB Standard Plasterboard,
• 6mm fibre cement sheet,
• 12mm plywood
• Exposed timber floors/ceilings (underside only)

• 13mm GIB Standard Plasterboard,
• 6mm fibre cement sheet,
• 12mm plywood
• Exposed timber floors/ceilings (underside only)

• FBL-100 may be used in Category C1 (Very Low) and C2 (Low) environments

Show more

• B2.3.1 Performance — Building elements must, with only normal maintenance, continue to satisfy the performance requirements of this code for the lesser of the specified intended life of the building, if stated, or (c) 5 years if:
  • (i) The building elements (including services, linings, renewable protective coatings, and fixtures) are easy to access and replace, and
  • (ii) Failure of those building elements to comply with the building code would be easily detected during normal use of the building

• (i) The building elements (including services, linings, renewable protective coatings, and fixtures) are easy to access and replace, and
• (ii) Failure of those building elements to comply with the building code would be easily detected during normal use of the building

• FBL-100 has been tested and assessed to:
• AS 1530.4:2014 – Methods for fire tests on building materials, components and structures: Fire resistance tests for elements of construction; and
• ISO 9705:1993 — Fire Tests: Full-scale room test for surface products
• As per the following:
  • Appendix C (normative) Test Methods of any of the NZBC – C/Acceptable Solutions (C/AS2 — C/AS6)
  • Appendix A (normative): Establishing Group Numbers for lining materials of  NZBC – C/Verification Method Two (C/VM2)
• Therefore, is able to be used where the New Zealand Building code calls for a Fire Resistance Rating (FRR) or where a Group 2-S or better Interior Lining is needed

• AS 1530.4:2014 – Methods for fire tests on building materials, components and structures: Fire resistance tests for elements of construction; and
• ISO 9705:1993 — Fire Tests: Full-scale room test for surface products

• Appendix C (normative) Test Methods of any of the NZBC – C/Acceptable Solutions (C/AS2 — C/AS6)
• Appendix A (normative): Establishing Group Numbers for lining materials of  NZBC – C/Verification Method Two (C/VM2)

• FBL-100 has been designed to achieve a NZBC Group Number for surface finishes as per Appendix A of NZBC C/VM2.FBL-100 has been tested and assessed to achieve a Group 2-S on Type 1 substrates or better as per Appendix A1.6 Table A2 of NZBC C/VM2

All relevant certificates, assessments and reports are available upon request.
