IBS RigidRAP and RigidRAP-XT: Rigid Air Barriers Manufactured by Kiwis for Kiwis

With the uncertainty and shipment delays of the global supply market, nationwide shortages are gradually rising. Building projects in New Zealand are going through massive delays, pushing builders and architects to look for alternatives in order to be able to complete their projects.

For the past 30 years, IBS (Independent Building Supplies) has been sourcing and providing products for kiwis to build better homes. The 100% New Zealand owned company understands the building industry's increasing demand for locally manufactured products.

IBS RigidRAP and RigidRAP-XT are the only dual-layer and tri-layer rigid air barrier systems available on the New Zealand market and are also manufactured locally. These 8mm and 18mm OSB3 boards are engineered in Germany and then laminated with a BRANZ-appraised building paper here in New Zealand.

Lightweight, easy to cut, nail or screw, RigidRAP and RigidRAP-XT can speed up the building process by up to nine weeks for a standard three-bedroom home. The products can be exposed to the weather for up to 90 days and replace traditional building paper wrap. The boards can also be used as temporary weather cladding as well as providing structural bracing.

IBS understands that having supplies readily available is crucial for architects and builders to deliver projects on time and budget. In order to guarantee supply timeframes, IBS is getting RigidRAP and RigidRAP-XT boards manufactured every day to respond to the increasing demand. IBS is also able to reduce delivery delays by having months' worth of materials for manufacture secured and with more coming in the country every month.

As kiwis move towards more sustainable, durable and local products, RigidRAP and RigidRAP-XT are filling the need for a readily available rigid air barrier system in New Zealand.

RigidRAP and RigidRAP-XT are available in 2440 x 1196mm, 2745 x 1196mm and 3050 x 1196mm sheets and can be used with a multitude of approved tapes. These well-liked products are CodeMark certified and have a suite of product documents including the PASS and have even become standard building features for some builders and architects.

IBS RigidRAP and RigidRAP-XT are stocked by several merchant stores but can also be ordered in directly via your local merchant. IBS is currently able to complete orders and deliver in less than 10 business days.

IBS RigidRAP and RigidRAP-XT — responding to the building industry's demand for sustainable, local and readily available products.

IBS RigidRAP-XT

Independent Building Supplies

View Product

IBS RigidRAP®-XT is an 8mm OSB3 (Oriented Strand Board) which has been manufactured specifically for New Zealand, for use as a bracing element and/or rigid air barrier.

Scope of use as an external wall bracing

IBS RigidRAP-XT may be used as a bracing element within the following scope:

In wind zones:

Up to and including extra high as defined in NASH standard Part Two 2019 “Light Steel Framed Building”
Up to 2.5 kPa ULS where the building is specifically engineered

Building scope

New buildings.
In conjunction with concrete and timber subfloor applications that comply with the NZBC
With all cladding types that comply with NZBC
In conjunction with a drained and ventilated nominal 20mm cavity system
With aluminium joinery complying with the NZBC. IBS RigidRAP-XT may be used as a bracing element in existing buildings, however in these cases IBS makes no claim as to the bracing value that will be achieved
Existing concrete and timber sub-floor structures where the designer and/or installer have assured themselves that the existing building is suitable for the intended building work

Scope of use as a rigid air barrier

Applied to the outer face of the exterior framing, IBS RigidRAP-XT will minimise the pressure difference across the wall construction, thereby forming part of a weathertight external envelope. When installed in accordance with Section 4, IBS RigidRAP-XT performs the function of a rigid air barrier with bracing capacity.

If designed, used, installed and maintained in accordance with the scope, this product will meet the following provisions of the NZBC:

B1 Structure: B1.3.1, B1.3.2, B1.3.3(a, b, f, h), B1.3.4
B2 Durability: B2.3.1(a), B2.3.2
E2 External moisture: E2.3.2 (contributes to), E2.3.7
E3 Internal moisture: E3.3.1 (contributes to)
F2 Hazardous building materials: F2.3.1
H1 Energy efficiency: H1.3.1 (contributes to), H1.3.2E (contributes to)

IBS RigidRAP-XT meets all the requirements of Table 23 of E2/AS1 from the compliance document for the NZ Building Code (NZBC).

Structure

Durability

External Moisture

Internal Moisture

Hazardous Building Materials

Energy Efficiency

CodeMark

IBS RigidRAP

Independent Building Supplies

View Product

IBS RigidRAP® is an 8mm OSB3 (Oriented Strand Board) which has been manufactured specifically for New Zealand, for use as a bracing element and/or rigid air barrier.

IBS supply IBS RigidRAP for use as an internal or external wall bracing element when used in conjunction with a specific fixing system.

IBS RigidRAP may be used as a bracing element within the following scope:

In wind zones:

Up to and including extra high.
Up to 2.5kPa ULS where the building is specifically engineered.

Building scope

New buildings: with timber wall framing complying with NZBC
In conjunction with the GIB HandiBrac® method or a Strap Bracing system
In conjunction with LVL System - staples, Mitek CPC 80 and SPAX screws
In conjunction with LVL System - staples, Simpson Strong-Tie DTT2Z and type 17 screws
In conjunction with concrete and timber subfloor applications that comply with the NZBC
With all cladding types that comply with NZBC
In conjunction with a drained and ventilated nominal 20mm cavity system
With aluminium joinery complying with the NZBC
IBS RigidRAP may be used as a bracing element in existing buildings, however in these cases IBS makes no claim as to the bracing value that will be achieved

If IBS RigidRAP is to be installed as a bracing element in existing timber framed buildings, the following scope applies:

Existing timber framed buildings where the designer and/or installer have assured themselves that the existing building is suitable for the intended building work
Existing concrete and timber sub-floor structures where the designer and/or installer have assured themselves that the existing building is suitable for the intended building work

If designed, used, installed and maintained in accordance with the scope, this product will meet the following provisions of the NZBC:

B1 Structure: B1.3.1, B1.3.2, B1.3.3(a, b, f, h, m, q), B1.3.4
B2 Durability: B2.3.1(a)
E2 External Moisture: E2.3.2, E2.3.7
F2 Hazardous Building Materials: F2.3.1

Structure

Durability

External Moisture

Hazardous Building Materials

CodeMark
