The system is a proprietary high-performance wall system that provides horizontal fire and acoustic separation between adjacent tenancies in the same building.

The core component of the system is a high-tech Autoclaved Aerated Concrete (ACC) panel and aluminium bracket installed between traditional timber framing, insulated and plasterboard lined on the outer face. A cavity is created between the ACC panel and the timber framing through the use of a proprietary inter-tenancy aluminium bracket. The Hebel Intertenancy System is suitable for use in medium and high-density housing, e.g. terraced housing.

Show more

The Hebel PowerPanelXL / PowerPanel50 Intertenancy Wall System is compliant with the performance requirements of the New Zealand Building Code (NZBC) as evidenced by achieving CodeMark product certification.

If designed, used and maintained in accordance with the scope of CodeMark certificate CM20222, Hebel PowerPanelXL / PowerPanel50 Intertenancy Wall System will meet the following provisions of the NZ Building Code:

• Clause B1 Structure — B1.3.1, B1.3.2, B1.3.3(a,b,c,f,i,j,m,q); B1.3.4
• Clause B2 Durability — B2.3.1(a); B2.3.2
• Clause C3 Fire affecting areas beyond the fire source — C3.4(a); C3.6
• Clause C6 Structural stability — C6.2; C6.4
• Clause F2 Hazardous building materials — F2.3.1
• Clause G6 Airborne and impact sound — G6.3.1

Show more

CodeMark

• PowerPanelXL are for use as non-loadbearing external wall cladding system. It is designed to be installed on either timber or steel structural framing where domestic construction techniques are used for buildings less than or equal to 10m in height.
• It is designed to be installed on either timber or steel structural framing where domestic construction techniques are used for buildings less than or equal to 10m in height.

Show more

CSR Hebel PowerPanel XL, if designed, used, installed & maintained in accordance with the scope of the CodeMark Certificate, will meet the following provisions of the NZBC:

• Clause B1 Structure — B1.3.1; B1.3.2; B1.3.3(a, e, f, h, i, m); B1.3.4
• Clause B2 Durability — B2.3.1(b)
• Clause C3 Fire affecting areas beyond the fire source — C3.4(a); C3.5; C3.6 (contributes to); C3.7(a)
• Clause E2 External moisture – E2.3.2; E2.3.3; E2.3.5 (contributes to); E2.3.7
• Clause F2 Hazardous building materials — F2.3.1
• Clause H1 Energy efficiency provisions — H1.3.1; H1.3.2E (contributes to)

Show more

CodeMark

• PowerPanel50 are for use as non-loadbearing external wall cladding system. It is designed to be installed on either timber or steel structural framing where domestic construction techniques are used for buildings less than or equal to 10m in height.
• PowerPanel50 is lightweight steel-reinforced Autoclaved Aerated Concrete (AAC) panels mounted vertically on cavity battens, screw fixed to the structural framing.
• The product is for use in Importance Level 1 and Importance Level 2 buildings up to and including three storeys high that are less than or equal to 10m in height and situated in wind zones up to and including Extra High as determined in NZS 3604:2011 – Timber-framed buildings and NASH Standard Part 2:2019 Light Steel Framed Buildings.

Show more

CSR Hebel PowerPanel 50, if designed, used, installed & maintained in accordance with the scope of the CodeMark Certificate, will meet the following provisions of the NZBC:

• Clause B1 Structure — B1.3.1; B1.3.2; B1.3.3(a, e, f, h, i, m); B1.3.4
• Clause B2 Durability — B2.3.1(b)
• Clause C3 Fire affecting areas beyond the fire source — C3.4(a); C3.5; C3.6 (contributes to); C3.7(a)
• Clause E2 External moisture – E2.3.2; E2.3.3; E2.3.5 (contributes to); E2.3.7
• Clause F2 Hazardous building materials — F2.3.1
• Clause H1 Energy efficiency provisions — H1.3.1; H1.3.2E (contributes to)

Show more
