Hebel Panels Bring Maximum Durability to Commercial Projects

Whether it’s a single dwelling, high-rise apartment block or new commercial facility, material selection is one of the most important decisions to make during a new build. Here are some ways Hebel provides solutions to common pain points in the construction process.

Enhancing productivity with PowerPanelXL Wall Systems

Whether you’re building schools or offices, apartments or dual-occupancy homes, solid external and internal walls are essential. With steel reinforcement for added strength, plus an anti-corrosion layer for maximum durability, Hebel’s wall systems are a reliable long-term investment. The reduction in labour costs is also a big factor as to why developers are now looking to use Hebel Service Panels as an attractive alternative to other fire-rated service products on the market. One Hebel panel provides the same coverage as 75 traditional bricks!

Exceeding Fire Safety Ratings

Hebel's products also exceed fire safety requirements, giving residents peace of mind. The majority of walls only require a 60-minute fire rating, but Hebel Powerpanels are tested to a 90-minute system, meaning in the unfortunate occurance of a fire, residents have a longer time window before fire spreads to a corridor or the neighbouring apartment.

CodeMark certified, Hebel stands as a versatile, durable, and easy-to-install building material, offering a wide range of applications and solutions for construction projects of various scales. It’s decided, from façade to floor to fence, Hebel is the provider of choice for AAC or aerated concrete cladding.

Mitigating the Hum

CSR Hebel's innovative system ensures quality control in noise reduction measures. Its versatility and effectiveness make it a valuable solution for challenges posed by urban expansion and electricity substations. Utilising the Hebel Powerpanel50 in a system, allows for absorption of low-frequency noise.

Overcoming Structural Constraints with Powerfloor+

Hebel's PowerFloor+ system has gained popularity among developers in New Zealand, proving to be a smart solution for various construction projects.

When approaching an office project, there is a need for a lighter flooring solution. Hebel's lightweight nature plays a pivotal role in this, as using heavier flooring options poses structural challenges, potentially limiting the construction to two office floors. Hebel's lightweight design enables the addition of a third office floor.

PowerPanelXL 75mm External Wall System

Hebel

View Product

Hebel PowerPanelXL External panels for walls are lightweight steel-reinforced Autoclaved Aerated Concrete (AAC) panels, the panels have been designed to be lighter than standard PowerPanel without compromising the structural integrity of the panel.

PowerPanelXL are for use as non-loadbearing external wall cladding system. It is designed to be installed on either timber or steel structural framing where domestic construction techniques are used for buildings less than or equal to 10m in height.
It is designed to be installed on either timber or steel structural framing where domestic construction techniques are used for buildings less than or equal to 10m in height.

CSR Hebel PowerPanel XL, if designed, used, installed & maintained in accordance with the scope of the CodeMark Certificate, will meet the following provisions of the NZBC:

Clause B1 Structure — B1.3.1; B1.3.2; B1.3.3(a, e, f, h, i, m); B1.3.4
Clause B2 Durability — B2.3.1(b)
Clause C3 Fire affecting areas beyond the fire source — C3.4(a); C3.5; C3.6 (contributes to); C3.7(a)
Clause E2 External moisture – E2.3.2; E2.3.3; E2.3.5 (contributes to); E2.3.7
Clause F2 Hazardous building materials — F2.3.1
Clause H1 Energy efficiency provisions — H1.3.1; H1.3.2E (contributes to)

Structure

Durability

Protection from Fire

External Moisture

Hazardous Building Materials

Energy Efficiency

CodeMark

PowerPanel50 External Wall System

Hebel

View Product

Hebel PowerPanel50 External Wall panels are lightweight steel-reinforced Autoclaved Aerated Concrete (AAC) panels, these panels been designed thinner without compromising the structural integrity of the panel.

PowerPanel50 are for use as non-loadbearing external wall cladding system. It is designed to be installed on either timber or steel structural framing where domestic construction techniques are used for buildings less than or equal to 10m in height.
PowerPanel50 is lightweight steel-reinforced Autoclaved Aerated Concrete (AAC) panels mounted vertically on cavity battens, screw fixed to the structural framing.
The product is for use in Importance Level 1 and Importance Level 2 buildings up to and including three storeys high that are less than or equal to 10m in height and situated in wind zones up to and including Extra High as determined in NZS 3604:2011 – Timber-framed buildings and NASH Standard Part 2:2019 Light Steel Framed Buildings.

CSR Hebel PowerPanel 50, if designed, used, installed & maintained in accordance with the scope of the CodeMark Certificate, will meet the following provisions of the NZBC:

Clause B1 Structure — B1.3.1; B1.3.2; B1.3.3(a, e, f, h, i, m); B1.3.4
Clause B2 Durability — B2.3.1(b)
Clause C3 Fire affecting areas beyond the fire source — C3.4(a); C3.5; C3.6 (contributes to); C3.7(a)
Clause E2 External moisture – E2.3.2; E2.3.3; E2.3.5 (contributes to); E2.3.7
Clause F2 Hazardous building materials — F2.3.1
Clause H1 Energy efficiency provisions — H1.3.1; H1.3.2E (contributes to)

Structure

Durability

Protection from Fire

External Moisture

Hazardous Building Materials

Energy Efficiency

CodeMark

Hebel Low-Rise Multi-Residential PowerPanelXL / PowerPanel50 Intertenancy Wall System

Hebel

View Product

CSR Hebel PowerPanelXL / PowerPanel50 Intertenancy Wall System is a lightweight non-loadbearing wall construction system suitable for use in low-rise residential buildings, that provides a fire rating of up to 90/90/90, and an STC rating between 58-65.

The system is a proprietary high-performance wall system that provides horizontal fire and acoustic separation between adjacent tenancies in the same building.

The core component of the system is a high-tech Autoclaved Aerated Concrete (ACC) panel and aluminium bracket installed between traditional timber framing, insulated and plasterboard lined on the outer face. A cavity is created between the ACC panel and the timber framing through the use of a proprietary inter-tenancy aluminium bracket. The Hebel Intertenancy System is suitable for use in medium and high-density housing, e.g. terraced housing.

The Hebel PowerPanelXL / PowerPanel50 Intertenancy Wall System is compliant with the performance requirements of the New Zealand Building Code (NZBC) as evidenced by achieving CodeMark product certification.

If designed, used and maintained in accordance with the scope of CodeMark certificate CM20222, Hebel PowerPanelXL / PowerPanel50 Intertenancy Wall System will meet the following provisions of the NZ Building Code:

Clause B1 Structure — B1.3.1, B1.3.2, B1.3.3(a,b,c,f,i,j,m,q); B1.3.4
Clause B2 Durability — B2.3.1(a); B2.3.2
Clause C3 Fire affecting areas beyond the fire source — C3.4(a); C3.6
Clause C6 Structural stability — C6.2; C6.4
Clause F2 Hazardous building materials — F2.3.1
Clause G6 Airborne and impact sound — G6.3.1

Structure

Durability

Protection from Fire

Hazardous Building Materials

Airborne and Impact Sound

CodeMark

PowerFloor

Hebel

View Product

Hebel PowerFloor panel system is a high-performance lightweight AAC flooring system.

Hebel PowerFloor systems are joist floor solutions for residential, low rise multi-residential, commercial and industrial construction.

The floor applications consist of a Hebel PowerFloor panel connected to a steel or timber joist system forming a platform floor.

CSR Hebel PowerFloor, if designed, used, installed & maintained in accordance with the scope of the CodeMark Certificate, will meet the following provisions of the NZBC:

Clause B1 Structure — B1.3.1; B1.3.2; B1.3.3(a, b, f, i, j, m); and B1.3.4.
Clause B2 Durability — B2.3.1(a); and B2.3.2.
Clause C3 Fire affecting areas beyond the fire source — C3.4(a); C3.6.
Clause C4 Movement to place of safety — C4.3 (contributes to).
Clause C6 Structural Stability – C6.2 (contributes to).
Clause F2 Hazardous building materials — F2.3.1.
Clause G6 Airborne and impact sound — G6.3.1; and G6.3.2.
H1 Energy efficiency – H1.3.1(a) (contributes to); and H1.3.2E (contributes to).

Structure

Durability

Protection from Fire

Hazardous Building Materials

Airborne and Impact Sound

Energy Efficiency

CodeMark
