Change is Coming, Let's Make it Easy

In a bid to become carbon-neutral by 2050, MBIE has set out to find a way to be a part of achieving this goal with the Building for Climate Change programme. By mid-May, new homes will require higher levels of insulation, which will in turn deliver warmer, drier and healthier homes that cost significantly less to heat whilst also generating carbon savings through this energy efficiency. Whilst the H1 change will create a more thermally efficient home, the roofing costs will increase, and there are still minimal solutions to accommodate these changes.

DriSpace has made it easy, with DriSpace H1 Solution systems, which are cost-efficient and accommodate increased insulation requirements (R6.6) in roof and wall. Passive ventilation in the roof space has always been imperative to ensure mildew, mould and condensation are kept at bay, with the new minimum, the thicker insulation has a greater risk of touching the underlays as a result of the reduced roof space.

With some key products such as the VENT Roll Panel/Eaves Baffle Vent, VENT Over Fascia Vent and VENT Ventilation and Drainage Battens in conjunction with DriStud vapour permeable underlays and ProctorPassive airtight membranes, an energy-efficient, airtight home with passive ventilation that meets the new H1 requirements can be achieved. DriSpace is making it easy — offering H1 Solutions for any roof pitch and design.

Literature:

VB10 —Ventilation and Drainage Roof Batten

DriSpace

View Product

DriSpace VENT VB10 is a Polypropylene Ventilation and Drainage Batten deigned to facilitate passive airflow and cavity drainage between the roofing underlay or membrane and the roof cladding.

Recommended for skillion and trussed roofs
Highly recommended for roofs with cladding profiles with a large area of surface contact with roofing underlays i.e. trapezoidal or deep trough profiles
Commercial and residential application
To be used as part of proprietary DriSpace ventilation system

VENTs Passive Roof Ventilation Products comply with the following provisions of the NZ Building Code:

B1.3.1, B1.3.2
B1.3.3 (a)
B1.3.4 (a, b, c, d, e)
B2.3.1 (a)
B2.3.2 (a)

Evidence: All products are manufactured by Manthorpe Building Products Ltd (UK) who are ISO 9001 accredited by SGS Certificate # GB12/84769, certified since 2011.

BRANZ Appraised

G1200N Over Fascia Vent

DriSpace

View Product

The G1200N Over Fascia Vent is designed to discreetly ensure a positive airflow into the roof space between the roof membrane and the fascia board.

Suitable for roof pitches >15°
Compatible with timber or metal fascia
Suitable for new builds or renovations
Should be used in conjunction with the Roll Panel/Eaves Baffle Vent (G502) to ensure continuous and unimpeded airflow past the insulation
To be used as part of a proprietary ventilation system

Insect proof — 4mm vents prevent ingress of nesting insects
Warranty: 15 years

G1275 Eaves Comb Filler

DriSpace

View Product

The Eaves Comb Filler G1275 is designed with flexible fingers which adjust to fill the gaps left when using profiled tiles or steel roof cladding.

Commercial and residential application
Suitable for use on all roof types

G2500N Over Fascia Vent

DriSpace

View Product

The G2500N Over Fascia Vent is designed to discreetly ensure a positive airflow into the roof space between the roof membrane and the fascia board.

Suitable for roof pitches <15° and all skillion roofs
Compatible with timber or metal fascia
Suitable for new builds or renovations
Should be used in conjunction with the Roll Panel/Eaves Baffle Vent (G502) to ensure continuous and unimpeded airflow past the insulation
To be used as part of a proprietary ventilation system

G502CL Roll Panel Vent/Insulation Guard

DriSpace

View Product

The VENT Roll Panel/Eaves Baffle Vent G502CL is designed to maintain a continuous 25mm air gap between the underside of the roofing membrane or sarking board and loft insulation at the eaves, providing a consistent flow of air into the roof space.

Should be used in conjunction with other soffit/fascia vents to provide a complete passive ventilation system
For use on trussed roof designs of any degree pitch
Should be used as part of a proprietary system for trussed roof system

Warranty: 15 years
