PLT panels are suitable for use as floor and roof structures including diaphragm applications:

• In any wind zone or calculated wind pressure (ULS)
• In all exposure zones, excluding microclimates as defined in NZS 3604:2011
• In conjunction with a primary structure that complies with the NZ Building Code or where the designer has established that the existing structure is suitable for the intended building work
• In all hazard classes up to and including H3.2.
• As a diaphragm where specifically designed.
• In applications where NZ Building Code Clause C6 (structural stability) obligations apply.
• Woodspan PLT Panels may be used with residential and commercial floor loadings up to 3.0kPa
• Available in 90mm, 117mm and 140mm thicknesses giving multiple spanning options. Maximum panel size 7200mm x 890mm

• Specific design required for fixing capacity where the wind zone is greater than extra high or the ULS is greater than 2.5 kPa
• Fastening materials to be in accordance with NZS 3604:2011
• Where uses a diaphragm the design of connections to bracing elements is subject to specific design
• In applications where NZ Building Code Clause C6 (structural stability) obligations apply, the use of Woodspan PLT Panels is subject to specific design by a fire engineer
• Floor loadings up to 3.0kPa — specified fixings to meet floor loadings and floor panel thickness

If designed, installed and maintained in accordance with all Woodspan requirements, Woodspan PLT Panels will comply with or contribute to compliance with the following performance claims:

• B1 Structure: B1.3.1 B1.3.2 B1.3.3 (a, b, c, f, i, j, m, q) B1.3.4 (a, b, c, d, e) — Verification Method B1/VM1, AS/NZS 1170:2002 set, AS/NZS 1328:1998 (parts)
• B2 Durability B2.3.1 (a) B2.3.2 (a) — Acceptable Solution B2/AS1
• C6 Structural Stability C6.2 C6.3 — Verification Method B1/VM1, NZS 3603:1993
• F2 Hazardous Building Materials F2.3.1

• Adhesive is Purbond, a Type 1, one component polyurethane adhesive in accordance with AS/NZS 4364 and suitable for all service classes
• FSC [22/12/2020] Single Chain of Custody and Controlled Wood FSC-C006125
• Grade Right NZ Ltd. [01/08/2020]. Grade Verified Engineered Wood Products QA Programme
• Grade Right NZ Ltd [30/03/2019]. Member of Treat Right Programme
• Grade Right NZ Ltd. [31/03/2019]. Member Certificate Producer Grade Verified Structural Timber
