Residential A-Series Elevator
Description

Smooth ride, effective use of space, stylish colours, and a surprisingly low price tag, the Residential A-Series elevator is perfect for medium-density developers or group home builders looking for a practical blend of convenience, affordability, quality, and style.

The Powerglide A-Series elevator features Powerglide's proprietary hydraulic drive which provides a ride of unparalleled smoothness and stability as well as being quiet enough to install in any area of the home.

Powerglide have simplified the specification process by narrowing the A-Series to two car configurations, and car sizes that suit the two most common shaft sizes used by architects when making the most of tight spaces. Powerglide offer an easy online ordering process backed by an industry-leading support team, and will provide all required CAD documentation to complete the design, along with documentation to a standard accepted by all New Zealand consenting authorities.

A-Series is available in a choice of 11 stylish colours from traditional to statement colour pops, and comes with a comprehensive 3 year warranty.

Configurations

  • The A-Series is available in either Full Car (with three solid walls and a ceiling) or Open Car (one solid wall only)
  • Car sizes to suit 1m x 1m and 1.2m x 1.2m lift shafts only
Key Features

Recommended for:

  • Projects with limited space and/or limited budget

Configurations:

  • Full Car & Open Car

Styling:

  • Choice of 11 stylish colours

Proprietary Hydraulic Technology:

  • Lift runs on its own rails; does not require a specially engineered lift shaft
  • Guide rail system significantly reduces sideways movement for greater stability

Speed:

  • 150mm per second

Safety:

  • Safe exit during power failure; returns lift to the lower level to allow safe exit

NZ Design & Build:

  • Minimal lead time; design & manufacture from 8 weeks, versus 30+ for imported lifts
  • Seamless in-house design-build-installation service
  • 95% local componentry; easy access to parts
Scope of Use
  • Suitable for new designs or retrofits
  • Up to 3 stops or 7m of travel
  • Full car or Open Car configuration
  • Car sizes to suit 1m x 1m and 1.2m x 1.2m lift shafts only
  • Car height up to 2200mm
  • Load capacity maximum: 250kg
Limitations on Use
  • Travel limited to 7m
  • Maximum of 3 stops
  • No doors on lift car
  • Requires ceiling height at top level of at least 2300mm
  • Requires pit depth of at least 300mm, travel of <3600mm requires cylinder caisson inserted into ground
Statement of Building Code Compliance
  • This lift complies with this NZ Building Code Standard: NZS 4334:2012.
  • These are the relevant NZ Building Code clauses for this class of lift, and this lift complies with all of these clauses: B1, B2, D2/AS2, F8
Other Performance Attributes
  • 3 year warranty
