Topglass FR50 & FR60 by Alsynite

Topglass FR50 & FR60

Description

The Topglass Fire Retardant (FR) range is designed and supplied as fire and smoke retardant natural lighting and cladding solutions for use in commercial and industrial buildings.

Alsynite offer different grades of Fire Retardant translucent sheeting and cladding: Topglass FR50 (NZBC Group 3); and Topglass FR60 (NZBC Group 2).

Key Features

Topglass FR50 is glass reinforced polyester fire retardant sheeting that has been specifically formulated using fire retardant materials for use in commercial building applications and educational institutions.
Topglass FR50 is glass reinforced polyester fire retardant sheeting that can be considered into building designs that specifically require reduced ignitability, flame propagation and heat and smoke release over conventional resin systems.

Scope of Use

Applications:

Schools and educational institutions
Public assembly areas
Combustible areas with high fire risk
Where egress from a building in the event of fire may be restrictive

Statement of Building Code Compliance

Topglass/TopcladTM FR50 has been extensively tested using the cone calorimeter ISO 5660 and AS/NZS 3837 test method and also the full scale ISO 9705 room test. This extensive testing utilises a gas burner exposing the sheeting to 100kw for 10 minutes, and then 300kw for a further 10 minutes until flashover is reached.
Topglass FR50 achieves a Building Code (NZBC) group number 3 in both these tests
Topglass FR50 has also recently been tested to BS 476
Topglass/TopcladTMFR60 This grade has been cone calorimeter tested to ISO 5660 and AS/NZS 3837 and achieves a Building Code (NZBC) group number 2 rating
