• Common sheet sizes: 2400 x 400 x 15mm / 3740 x 400 x 15mm
• Suitable for home renovations, sheds, beach houses, garages, and workshops — where high impact resistance is required
• Paint-ready. MDF surfaces offer a grade 5+ paint finish capability
• Easy to install. The panels are light enough for a one man installation

Tongue and Groove joint:

• Each TGV panel is 400mm wide and it may be that the stud centres are not at 400 or, if lining a Portal or Pole shed, it’s likely that there will be no studs at all. Having a Tongue and Groove joint between the Triboard panels means that it doesn’t matter what centres the studs are because no framing is needed behind the join.
• Or, in the case of having girts only in a portal building, you don’t need to install vertical nogs to support the edge of the sheet as you would for other lining products.

Triboard TGV as Wall Bracing:

• Owing to the narrow (400mm) width of a TGV panel, it is generally not suited to installation as bracing as the fixings required to the bottom plate are prohibitive
• Should Wall Bracing be required, full size Triboard sheets are available in 10mm and 15mm. Bracing figures compliant with NZS3604 are available from Juken.

Fixing Triboard TGV Panels to the frame:

• When lining Steel Portal Sheds:
  • Self-Tapping 8g screws suitable for light gauge steel with Drill or Winged points, fixed into the horizontal girts
  • Girts should be at no more than 1.0m spacing vertically
  • The screws are recommended at approximately 180mm centres in each panel. (3 per panel per girt)
• When lining a Timber Portal or Pole Farm Shed:
  • Use 8g CSK wood screws 35-40mm long into the girts
  • Install screws to the same fixing pattern as for steel (3 per panel per girt)
  • The same fixing is appropriate into the horizontal nogs of conventionally framed timber walls

• Self-Tapping 8g screws suitable for light gauge steel with Drill or Winged points, fixed into the horizontal girts
• Girts should be at no more than 1.0m spacing vertically
• The screws are recommended at approximately 180mm centres in each panel. (3 per panel per girt)

• Use 8g CSK wood screws 35-40mm long into the girts
• Install screws to the same fixing pattern as for steel (3 per panel per girt)
• The same fixing is appropriate into the horizontal nogs of conventionally framed timber walls

Panel adhesive is recommended for all fixing types:

• As Triboard is not used as wall bracing, and therefore doesn’t perform a structural role, these fixing specifications are simply guidelines
• For less visible fixing, good results can also be obtained using gun fired nails or brads in conjunction with panel adhesive.

See Juken website for full information

Show more

• Improved impact resistance over some traditional internal lining solutions
• MDF surfaces offers a grade 5+ paint finish capability
• Made in New Zealand from a responsibly managed forest resource — Forest Stewardship Council (FSC) certified
