Ecoply Barrier Delivers Optimum Building Protection

Architects, designers, specifiers and builders are all committed to building excellence. They are demanding more efficient buildings without compromising high standards of product performance. The Ecoply Barrier rigid air barrier system has been developed to meet these challenges and is ready for consideration as part of a prefabricated solution.

Ecoply Barrier is a BRANZ appraised system manufactured by Carter Holt Harvey Woodproducts. The Ecoply Barrier system is a rigid air barrier for use with drained and vented cavity systems outside the building frame. It replaces traditional building wrap in the cavity and provides a strong secondary line of defence against moisture penetration into the building envelope.

The Ecoply Barrier system has a two step application; fasten the panels during the prefabrication process to the frame, and then apply the self-adhesive tapes to the seams either during prefabrication or alternatively when the prefabrication unit is on site, depending on the project's requirements.

Ecoply Barrier panels are H3.2 CCA treated 7mm thick structural plywood, with a factory applied low VOC powdercoat film that is formulated for use on Ecoply Barrier plywood panels. The powdercoat finish wraps around the edges to maximise protection and when used in conjunction with the Ecoply Barrier tape range, provides a weathertight seal around penetrations. The panels, coating and tapes are engineered to allow the wall system to breathe and dry out effectively.

Once designers experience the many benefits of using the Ecoply Barrier System in their next prefabrication project and see how easy it is to use and transport, they will not look back.

View more information on Carter Holt Harvey, including contact details.
