20 Years of Protecting Wet Areas in NZ

Locally made for NZ conditions, GIB Aqualine, with its special water-resistant core, has been proven to help protect wet areas from steam and moisture damage. With the 2014 introduction of 1350mm wide 10mm GIB Aqualine, the comprehensive range caters well for the needs of residential and commercial applications.

The GIB Aqualine Wet Area Systems has an independent BRANZ appraisal and is backed with Winstone Wallboards’ technical support, allowing users to continue to specify GIB Aqualine with confidence.

Facts about GIB Aqualine and wet area rooms:

Installed in over one million kiwi homes
No. 1 choice in wet area linings*
NZ’s most preferred tiling substrate*
Fully backed with a minimum 10 year warranty**
Fibreglass in the core and can be used in GIB EzyBrace Systems^#
Can be used in GIB Fire Rated Systems^##

For more information, call the GIB Helpline on 0800 100 442 or visit www.gib.co.nz/aqualine.

*Winstone Wallboards BRANZ Trade Survey December 2014.

**Refer to GIB Product and System Warranty for full details.

^#The fibreglass core means it can be used in high performing bracing elements. Bracing elements are required to have a durability of 50 years. GIB bracing elements are not to be located in shower cubicles or behind baths because of durability requirements, the likelihood of renovation and practical issues associated with fixed bracing elements to perimeter framing members. (Refer to the GIB Aqualine Wet Area Systems and GIB EzyBrace Systems literature).

^##In place of equivalent thickness GIB Fyreline.

GIB Wet Area Systems

GIB

View Product

Although able to cope with infrequent short-term exposure, standard gypsum plasterboard will have a shortened life expectancy when frequently exposed to water or moisture.

NZ Made

GIB Aqualine is ideal in situations where lining materials may be exposed more frequently to water or streams (particularly one-off events such as leakages or flooding of a room) because it features a water resistant wax polymer impregnated core.

Clause B1 Structure: The design and material specification for steel and timber framing used in GIB Aqualine systems must be in accordance with the performance requirements of NZBC Clause B1 (Structure).
Clause B2 Durability: When installed and maintained in accordance with this literature, GIB Aqualine tiled or vinyl covered systems have a serviceable life of at least 15 years. They comply with the requirements of NZBC Clause B2 for use in wet areas directly exposed to liquid water, e.g. showers, showers over baths and splash-backs. When used as a general wet area lining and maintained under normal dry internal conditions, GIB Aqualine systems have a serviceable life of at least 50 years and comply with NZBC Clause B2 for use within toilets, kitchens, bathrooms and laundries not directly exposed to liquid water.
Clause C3 Spread of Fire: GIB Fire Rated Systems provide passive fire protection in accordance with the requirements of NZBC Clause C3. When GIB Aqualine is substituted into fire rated systems in place of the equivalent thickness GIB Fyreline, the Fire Resistance Rating (FRR) of that system will be maintained.
Clause E3 Internal Moisture: When installed in accordance with this literature, tiled or vinyl covered GIB Aqualine systems may be used in areas directly exposed to liquid water, such as showers, to provide an impervious and easily cleaned wall surface.
Clause F2 Hazardous Building Materials: At no stage during handling, installation, or serviceable life does GIB Aqualine constitute a health hazard. It therefore meets the provisions of NZBC Clause F2.
Clause G6 Airborne and Impact Sound: GIB Noise Control Systems can be used to provide ratings for Sound Transmission Class (STC) and Impact Insulation Class (IIC) in accordance with the requirements of NZBC Clause G6.

All GIB unfinished plasterboard sheet materials achieve a Group 1-S interior fire rating to NZBC C/AS2-AS6, Table 4.1, following testing in accordance with ISO 5660.1 and ISO 5660.2.

BRANZ Appraised
