EPS Insulated Facade System
Description

The Rockcote Insulated Facade System incorporates the latest drained rainscreen facade construction technology which incorporates a 20mm or 40mm drainage cavity. This system is a composite, BRANZ appraised exterior plastered facade system made up of mechanically fixed EPS insulation boards, modified acrylic renders, weather protected base and low maintenance, versatile finishes to ensure the integrity and durability of the entire system.

This system carries a written 15 year Performance Guarantee, and 5 year Workmanship Warranty from a LBP Registered Rockcote Plasterer. The Rockcote Insulated Facade System comes complete with a premium Rockcote EdgeSeal Flashing suite for extra security from water penetration creating beautiful and durable exteriors.

Key Features
  • Drained Rainscreen Facade System
  • Hand plastered
  • Complete supply and install
  • Rockcote Performance Guarantee
  • Patented EdgeSeal window flashing suite
  • LWC — Steel Wire Reinforced Lightweight Concrete Panel
  • 'Genuine' Resene Colour Range
  • Rockcote OnSite Assistance programme
  • BRANZ appraised
Scope of Use
  • Designed to be used as an external cladding system for residential and light commercial type buildings where domestic construction techniques are used.
  • Suitable for NZS 3604 Wind Zones up to and including 'Extra High'

See BRANZ Appraisal  for full scope and limitations.

Limitations on Use
  • Must only be installed to vertical flat surfaces (except for tops of parapets, sills and balustrades, which must have a minimum 10° slope and be waterproofed in accordance with the technical literature)
NZS 3604 Earthquake Zone Very High suitable
Very High Earthquake Zone
Statement of Building Code Compliance
  • B1 Structure
  • B2 Durability
  • E2 External Moisture
  • F2 Hazardous Building Materials

See BRANZ Appraisal for full information.

Other Performance Attributes

This system carries a written 15 year Performance Guarantee, and 5 year Workmanship Warranty from a LBP Registered Rockcote Plasterer.

E2 External Moisture compliant
External Moisture
Documents
CAD/PDF (link to page on supplier website)
Specification Clause/Guide
Environmental Information
Independent Appraisal (BRANZ)
Maintenance Instructions
Warranty
Order Samples
Additional Information

Creating beautiful and durable exteriors with premium, trusted Rockcote and Plaster System product ranges.
