Direct Fix

The Weathertex Direct Fixed Selflok Panel Cladding System has been appraised as an external horizontally fixed wall cladding system to timber-framed buildings within the following scope:

• the scope limitations of NZBC Acceptable Solution E2/AS1, Paragraph 1.1; and,
• with a risk score of 0-6, calculated in accordance with NZBC Acceptable Solution E2/AS1, Table 2; and,
• situated in NZS 3604 Wind Zones up to, and including, Very High.

Cavity Fix — Timber Framing

The Weathertex Cavity Fixed Selflok Panel Cladding System has been appraised as an external horizontally fixed wall cladding for timber-framed buildings within the following scope:

• the scope limitations of NZBC Acceptable Solution E2/AS1, Paragraph 1.1 for timber-framed buildings; and,
• with a risk score of 0-20, calculated in accordance with NZBC Acceptable Solution E2/AS1, Table 2; and,
• situated in NZS 3604 Wind Zones up to, and including, Extra High.

Cavity Fix — Steel Framing:

The Weathertex Cavity Fixed Selflok Panel Cladding System has also been appraised as external horizontally fixed wall claddings for steel-framed buildings within the following scope:

• the scope limitations of NASH Building Envelope Solutions Paragraph 1.1 for steel-framed buildings; and,
• with a risk score of 0-20, calculated in accordance with NASH Building Envelope Solutions; and,
• situated in NASH Standard Part 2 Wind Zones up to, and including, Extra High.

See BRANZ Appraisals 511 and 512 for full information.

• Must only be installed horizontally on vertical surfaces
• Design details must follow the Weathertex design and installation documents
• Must be installed by a Licensed Building Practitioner (LBP)
• Appraised for use with aluminium window and door joinery that is installed with vertical jambs and horizontal heads and sills
• Joinery must meet the requirements of NZS 4211 for the relevant Wind Zone.

In the opinion of BRANZ, Weathertex Selflok Panel Cladding Systems, if designed, used, installed and maintained in accordance with the statements and conditions of BRANZ Appraisal 511 and 512, will meet the following provisions of the NZBC:

• Clause B1 STRUCTURE: Performance B1.3.1, B1.3.2 and B1.3.4. Meets the requirement for loads arising from self-weight, earthquake, wind, impact and creep [i.e. B1.3.3 (a), (f), (h), (j) and (q)].
• Clause B2 DURABILITY: Performance B2.3.1 (b) 15 years, B2.3.1 (c) 5 years and B2.3.2.
• Clause E2 EXTERNAL MOISTURE: Performance E2.3.2.
• Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1.

See BRANZ Appraisals 511 and 512 for full information.

Weathertex has been used in residential and commercial projects in New Zealand since 1980 and in Australia since 1930.

• Better than zero carbon footprint
• PEFC-certified timber for sustainable sourcing
• Green Tag Certified
• No added silica, resins, or formaldehyde
• Resistant to termites, rot, and fungal decay

Warranty

• 25 year guarantee — pre-primed
• 15 year guarantee — Natural
