CS Premier 2T-140
Description

CS WardrobeSliders are a complete sliding wardrobe door solution. As a unit they come complete with track, guides and all jamb liners. Installation is simply a case of securing the unit within the wall framing, then lining and finishing. The range of double and triple top track sliding wardrobe door systems allow for doors up to 40mm thick with no visible floor guides. Match wardrobe doors to other internal hinged or cavity sliding doors.

CS Wardrobes Premier 2T-140 is a complete wardrobe sliding door system that includes high quality track, carriages and timber head and closing jambs. CS Wardrobe Sliders incorporate the same quality track and carriage system that is used in CS Cavity Sliders, allowing the confident use of over-height and over-width wardrobe doors.
Because the wardrobe system is hung from the top track, there is no requirement for unsightly and inconvenient floor guides or tracks. Where the doors overlap, a small aluminium floor guide is fitted, providing invisible and reliable guidance for each door.

Cavity and wardrobe doors can be supplied from the same joinery manufacturer, as the same standard thickness doors that suit CS CavitySliders (38mm thick) can be used in CS WardrobeSliders. This uniformity ensures a consistent look between doors in a given area or throughout a building.

Operation: Choose from standard M6 (120kg) or M8 (240kg) carriages or SofStop Twin soft open & close (50kg)

For a triple top-track option, see the Premier 3T-190.



Key Features
  • Track is engineered from high quality heavy duty extruded aluminium
  • Door and carriages can be removed without removing wall linings
  • Fits into a standard thickness wall (140mm framing)
  • Doors cannot jump off the track
  • Available as 2, 3 or 4 door setups
  • Supplied fully assembled for on-site installation
  • No visible floor guides. Floor coverings may be laid through the opening, creating a neat finish

Detail Options

Incorporate any of the following architectural detail options with CS Premier 2T-140 to create a specific look or to provide a unique solution:

  • Full-Height
  • NoClosingJamb
  • ShadowLine
  • SquareStop
  • Extra-WideJambs
Categories
Storage
NZ Made
NZ Made
Scope of Use

Suitable for use with sliding doors in internal locations in residential, commercial and light industrial buildings.

  • Door thickness: 35-40mm
  • Maximum door weight: 240kg per door
  • Wall Framing: 140mm
In-Service History

CS Wardrobe Sliders have been successfully used in commercial and residential projects in New Zealand and Australia since 1994. CS Wardrobe Sliders are backed by a 10 year written guarantee.

Documents
Data Sheet
Maintenance Instructions
Warranty
Additional Information

CS Cavity Sliders (CS For Doors) are a manufacturer of cavity sliding door systems and related products.
