Armstrong Ultima OPDB
Description

Ultima OP dB family of ceilings provide the highest level of TOTAL ACOUSTICS™ Performance (NRC+CAC) producing the optimum flexible acoustic space. Featuring excellent sound absorption (NRC) for reduced reverberation and quieter spaces, along with outstanding sound attenuation (CAC) for improving room to room privacy. Ultima OP dB ceilings achieve Level A Green Tag Green Rate Certification and Platinum Product Health Declaration.

All Ultima ceilings feature a smoother, light reflective and durable surface and are available in a wide range of sizes and edge profiles to suit various PeakForm Steel and Blue Tongue Aluminium Grid systems.

  • Available in 30mm thick square edge and tegular edge as standard with other thicknesses available as special order products.
  • Material: Wet-formed mineral fibre with durable acoustically transparent membrane
  • Surface Finish: Factory applied acrylic paint
Key Features
  • The highest level of sound absorption and attenuationpossible for a ceiling panel producing the optimum flexible acoustic space
  • TOTAL ACOUSTICS™ Performance (NRC+CAC) options — outstanding sound attenuation, improving room to room privacy; excellent sound absorption for reduced reverberation and quieter spaces
  • Global GreenTag CERT™ GreenRate™ Level A Certified for Green Star™ contribution
  • Durable, reinforced, scratch resistant face
  • New smooth finish with high light reflective finish for a brighter space
  • Complete range of edge details
  • Humiguard™ Plus RH99 Sag Resistance
  • ISO 4 Clean Room Performance
Green Tag Certified
Green Tag Certified
Homestar / Green Star (Envirospec) Compliant
Homestar / Green Star
Scope of Use
Suitable for ceilings:
  • Private and open-plan offices, meeting & boardrooms
  • Classrooms and libraries
  • Auditoriums, cinemas, theatres
  • Cafeterias and restaurants
  • Consultation and patient rooms
  • Transport lounges and waiting areas
Tile sizes:
  • Standard size: 1200mm x 600mm x 30mm
  • Square Edge & Tegular Edge to suit 24mm grid systems
  • Note: 19mm and 35mm Square Edge and Tegular Edge are available via special order and come with minimum order quantities
  • Weight: 8.2kg/m²
Other Performance Attributes
  • Acoustic Performance: NRC: 0.90, CAC:41
  • Humidity Performance: RH99% at 0ºC – 49ºC — Humiguard™ Plus RH99 Sag Resistance
  • Fire Performance: Conforms with NCC Spec. C1.10 as tested to AS5637.1:2015 – Group 1, and ISO 5660 – Group 1S
  • ISO 4 Clean Room Performance
  • Global GreenTag CERT™ GreenRate™ Level A Certified for Green Star™ contribution
  • Recycled Content: 33-39%
Interior Fire Rating 1
1
Interior Fire Rating 1S
1S
Documents
Armstrong Ceiling Solutions Material Safety Datasheet
Armstrong Ceiling Solutions Mineral Fibre Installation Instructions
Armstrong Ceiling Solutions Sustainability Brochure
