Asona Triton Cloud VG
Description

TritonCloud™ VG are an economical, wrapped edge, high sound absorbing ceiling panel with a crisp tailored finish.

Panels are rigid and designed as free floating or direct fix elements to control reverberation. Available in a range of standard sizes and decorative finishes.

Key Features
  • Cloud VG are an economical, cost-effective option.
  • High sound absorption, up to αw/NRC 1.00, for noise control.
  • Fire Group 1-S.
  • Ministry of Education DQLS V3.1 2024 approved solution.
  • Range of standard sizes, and decorative finishes for design freedom. Large modules up to 1100 x 2300mm.
  • Wide range of mechanical fixing solutions to direct fix or suspend panels.
  • Dimensionally stable, rigid finish, no sag in hot conditions.
  • Light weight for seismic design advantage.
  • Easy to work on site using standard tools.
  • GreenTag Certified / Level A.
  • ISO 9001 registered quality management program.
  • Packaging take back and reuse scheme (NZ only).
  • Made in NZ, short lead times including replacement parts.
Green Tag Certified
Green Tag Certified
Recyclable Content (Post-Consumer)
Post-Consumer Recyclable Content
Recycled Content (Pre-Consumer)
Pre-Consumer Recycled Content
NZ Made
NZ Made
NZ-Owned Business
NZ-Owned Business
Scope of Use

TritonCloud™ VG panels are ideal for economic ceilings in open plan offices, classrooms, meeting rooms, halls, cafes and bars where control of noise is required.

  • Ministry of Education DQLS V3.1 2024 approved solution.
  • Range of standard sizes, and decorative finishes for design freedom. Large modules up to 1100 x 2300mm.
  • Wide range of mechanical fixing solutions to direct fix or suspend panels.
Limitations on Use
  • For interior use only, and not in direct contact with water.
  • Maximum humidity/temperature 99% R/H at 45°C.
  • Back loading — No overlay loads, M&E services and point loads to be independently supported.
Statement of Building Code Compliance

NZ Building Code Compliance:

  • B2 Durability – Clause B2.3.1 (c) (i): Asona Triton Cloud VG with only normal maintenance will have a minimum durability of at least 5 years when installed in accordance with; manufacturer’s installation requirements and AS/NZS 2785:2020.
  • C3 Fire – Clause C/AS2 3.4(a): Asona Triton Cloud VG has a Fire Material Group Number 1-S for Sonatex and selected fabric finishes and installation method, by NZBC verification method C/VM2 Appendix A, tested in accordance with ISO 5660 or ISO 9705.Other fabrics & installation method 2-S, 2 and 3. Please consult Asona.



In-Service History
  • 2 years, multi Ministry of Education new build and retrofit of existing schools.
  • various retail and commercial
Other Performance Attributes
  • Very high acoustic absorption performance — up to αw/NRC 1.00, for noise control
  • White finish has high light reflectance
  • NZ made
  • GreenTag Certified / Level A
  • ISO 9001 registered quality management program
  • Packaging take back and reuse scheme (NZ only)
Documents
Asona Cloud VG

24.09

Asona Ltd are a manufacturer, distributor and installer of acoustic and decorative ceiling and wall panels.
