Midfloor Acoustic Systems — SoundLite
Description

SoundLite is a complete finished floor system designed for buildings without a drop ceiling that is low cost, simple to install, and has a low build-up.

Suitable for both residential and commercial applications, SoundLite is best suited to medium-density housing and apartments. Typical installation is building spaces that have been converted to multi-tenanted apartments that are then required to meet acoustic levels. No stepped transitions to carpet products are required due to the low build-up.

Key Features
  • Small build-up (8.5mm flooring panel and 1mm underlay)
  • Simple installation
  • Cost effective



Scope of Use

Woodland's SoundLite acoustic system incorporates Metroflor Genesis waterproof vinyl flooring and floorMuffler LVT Underlay. Woodland recommend using SoundLite on slabs with a minimum thickness of 170mm without a drop ceiling.

Metroflor flooring is suitable for wet areas including bathrooms, kitchens and laundries.

System Details

IIC (on site test)

≥ 53dB

Build-up Thickness

9.5mm

Finish

Finished floor system

Installation

Floating

Slab Thickness

≥ 170mm

Limitations on Use
  • Not suitable for use inside showers or bathrooms with walk-in showers
  • Not suitable for high-traffic, heavy use areas
Other Performance Attributes

Woodland Lifestyle and our supply partners have conducted both laboratory and onsite tests on various slab thicknesses.

Build Up Test Type Slab Thickness IIC Minimum Requirement
Metroflor Genesis Lab Test

152mm

No Drop Ceiling

54dB 55dB
Metroflor Genesis Lab Test

152mm

With Drop Ceiling

69dB 55dB
Metroflor Genesis + floorMuffler LVT Onsite Test

175mm

No Drop Ceiling

53dB 50dB
Documents
BPIR/PTS
Technical Data Sheet
Acoustical Performance Test Report
Onsite Test report Genesis + floorMuffler LVT 175mm slab (no drop ceiling)
Product Overview

Woodland Lifestyle is a family-owned, New Zealand based business specialising in acoustic and hard flooring solutions for
both residential and commercial applications.
