FloorPly14® Structural Plywood
Description

IBuilt's FloorPly14® is New Zealand's strongest rated pine plywood flooring. Manufactured to AS/NZS 2269.0:2012 Plywood Structural standard. Certified by the Engineered Wood Products Association of Australasia (EWPAA) meeting the highest product quality and performance standards and come PEFC Chain of Custody certified. Available in 2.4m x 1.2m sheet lengths.

Key Features
  • F14/F14 stress grade
  • Tongue & grooved
  • Available H3.2 CCA or Untreated
  • E0 Formaldehyde emissions class
  • PEFC Chain of Custody certified

Products available:

  • CD — 15, 17, 19, 21, and 25mm
  • Carpet Grade — 19 and 21mm
Scope of Use
  • FloorPly14® structural plywood can be used in all internal applications where a structural rated plywood panel is required.
  • For like thicknesses it can be used in lieu of F8 and F11 sheets if required.
  • Applications include gussets, portals and membrane substrates.
  • When tongue and grooved (T&G) it can also be used as flooring and roofing.
  • H3.2 treated product can be used in external above ground applications.
Limitations on Use

Untreated plywood must not be used externally or in high moisture areas. Treated plywood must not be used in contact with the ground. It is not recommended to use smooth face plywood as a cladding - refer to IBuilt CoreClad™ which is manufactured specifically for exterior use. Ensure only compatible materials/fixings are in direct contact with H3 treated plywood. These products are not subject to a warning or ban under section 26 of the Act.

Statement of Building Code Compliance

FloorPly14® is manufactured for the New Zealand and Australian markets to meet the Australian and New Zealand standards: AS/NZS 2269.0:2012. All IBuilt Structural Plywood products meet the requirements of the New Zealand Building Code causes:



  • B1 Structure: B1.3.1, B1.3.2, B1.3.4(d)
  • B2 Durability: B2.3.1(a)
  • F2 Hazardous Building Materials: F2.3.1
PEFC Certified
PEFC Certified
Documents
BPIR Product Statement
Brochure

New Zealand Wood Products Ltd is a supplier of I-Built engineered timber, glulam, plywood and associated materials.
