Single Disc – MB75 by Metro Performance Glass

Single Disc – MB75

Metro Performance Glass

All products

Product Enquiries

Description

The Single Disc MB75 was born from testing and modelling balustrade fixings to determine the optimum economical fitting for clamp fixing balustrades. The outer disc was profiled to give an attractive appearance and the single fixing point means it can be located on the edge of narrow concrete slabs, steel or timber profiles.

Key Features

Single Disc MB75 is 75mm diameter
Inner spacer is 30mm thick and the outer plate 10mm thick
Single Disc MB75 is made from 316 grade stainless steel and is available in machine satin or polished finish.

The system is glazed with Metro Performance Glass:

The system is glazed with Metro Performance Glass, as follows:

10, 12 and 15mm TempaFloat Toughened Safety Glass
10, 12 and 15mm TempaSoak Heat Soaked Toughened Safety Glass
10, 12 and 15mm TempaPrint or TempaScreen Ceramic Frit Toughened Safety Glass
15.2 and 17.2mm Toughened Laminated Safety Glass with EVA interlayer.
13.52 and 17.52mm SafeLite Toughened Laminated Safety Glass with SentryGlas interlayer.

Ranges

Balustrade Hardware

Scope of Use

Single fixing point means the disc system can be located on the edge of narrow concrete slabs, steel or timber profiles.

Statement of Building Code Compliance

The System has been tested in NZ to AS/NZS 1170 barrier loadings in accordance with B1/VM1 Amendment 8.

Metro Performance Glass is at the forefront of providing high-performance glass products and glass expertise to the residential and commercial construction markets.
