Mapei Easy Lift Torch-On Tanking
Description

Easylift tanking membrane is a modified bitumen, torch applied membrane reinforced with a polyester spun bond glass thread and an upper surface of polyethylene film.

Easy lift is a versatile membrane provided with excellent mechanical strength, dimensional stability, and remarkable adhesion. These characteristics make Easy lift particularly superior when waterproofing vertical walls.

It is available in 3mm or 4mm thick, and supplied in 1m wide x 7.5m long rolls.

Key Features
  • BRANZ Appraised
  • Excellent mechanical strength, dimensional stability, and adhesion
  • 15 to 20 year durability warranty
Scope of Use

Torch applied membrane:

  • Single or double layer systems directly torched to floor slabs, footings , block walls and planter boxes
  • Precast concrete or in situ concrete complying with NZS 3101 or concrete masonry complying with NZS 4230 and 4210
Limitations on Use

Design requirements:

  • Easylift torchon tanking is for below ground footings, blockwalls, insitu or precast concrete. Installed in a single layer, or double layer system, fully protected

Installation requirements:

  • All substrates need to be primed before application. Application instructions for the primers are contained in the technical data sheets
  • Starting at the lowest point, the membrane must be installed in accordance with MBP (NZ) ltd technical literature. Sheet laps, edges and ends must be overlapped as per technical literature. Internal and external corners must be reinforced with an extra layer of membrane 300mm wide.
  • Protection must be installed (polyfond kit drain) before back filling. Back filling must commence immediately after the membrane is installed to ensure no long time exposure to sunlight or UV radiation

Application and workmanship:

  • The MBP (NZ) ltd contractor is solely responsible
  • Only to be installed by an approved MBP (NZ) ltd installer
  • Quality of installation on site is the sole responsibility of the MBP (NZ) ltd approved applicator
Statement of Building Code Compliance

This product will, if employed in accordance with the supplier's installation and maintenance requirements, assist with meeting the following provisions of the NZBC:

  • Clause B2 Durability: Performance B2.3.1(a)
  • Clause E2 External Moisture: Performance E2.3.3
  • Clause F2 Hazardous Building Materials: Performance F2.3.1
In-Service History
  • Member of New Zealand Green Building Council
Other Performance Attributes
  • ISO 9001 (Quality Management)

Warranty and Maintenance

Maintenance requirements:

  • Annual inspections must be made to membranes top edge seal and termination bar. Check all drainage outlets, to ensure all systems are functioning correctly. If required the drainage coil / or pipe must be cleared to remove any sediment or silt build up. The falls of the back fill capping must be maintained
  • Building Owners are responsible for the maintenance of the membrane system in accordance with MBP (NZ) Ltd. Maintenance and Care documents will be provided with every warranty application

Warranty:

  • 15 year durability warranty for a single layer system
  • 20 year Durability warranty for a 2 layer 3mm+3mm system



BRANZ Appraised
BRANZ Appraised
Documents
Technical Data Sheet

Rev 1/18

Product Technical Statement

Masterspec PTS 109340

Masterspec Work Sections
BRANZ Appraisal 804

804 [2019]

Mapei have over 80 years of experience, with innovative quality adhesives, sealants and chemical products and systems for the building industry.
