Engineered Timber Wood Flooring — Haven Collection
Description

Haven collection tells a story of quality and care, sourced responsibly and crafted with integrity to stand the test of time of engineered timber overlay flooring suitable for residential and commercial applications. Haven comes in pre-finished 14/3mm x 190mm x 1900mm, 15/4mm x 190mm x 2200mm, 21/6mm x 190mm x 1900mm in Plank, Herringbone and Chevron options. Planks are applied via glue-down installation onto a substrate.

Key Features
  • Ten colours with 60 variants, ensuring endless possibilities that bring your design vision to life.
  • Pre-finished UV cured matte lacquer for durability and protection
  • Stocked in Feature and Light Feature Grade
  • Stocked in 190mm wide planks
  • Matching stair nosings for a cohesive look
  • Premium three-layer engineered timber
  • 3mm, 4mm and 6mm European Oak Wear Layer — can be sanded and recoated up to 2x if required
  • Eucalyptus Plywood Core
  • PEFC® Certified
  • Low VOC — does not contain any added formaldehyde
  • 25 year residential warranty
  • 5year commercial warranty
Scope of Use

Overlay flooring suitable for residential and commercial applications.

  • Glue down installation over plywood, particle board, concrete, existing timber
  • 4-sided tongue and groove planks
  • Compatible with underfloor heating
  • Prefinished, can be sanded and recoated up to 2x if required
  • Matching stair nosing available

The Forté Timber Overlay Flooring System is certified for use in:

  • a) all buildings
  • b) in all areas, including level access routes likely to become wet, except:
  • i. garages and commercial kitchens, and
  • ii. unsprinklered sleeping areas and exitways in buildings where care or detention is provided, and
  • c) installed on the following substrates:
  • i. Concrete floors (slab-on-grade or suspended)
  • ii. Timber flooring (structural or overlay)
  • iii. Concrete floors with Hydronic Underfloor Heating system
  • iv. Electric underfloor heating system
  • v. Wet-Area Membrane systems
  • vi. Acoustic underlay
Limitations on Use

The Forté Timber Overlay Flooring System shall be:

  • a) designed in accordance with the design guide applicable to the product (Timber Overlay Flooring System Design Guide Edition 3.0 April 2023 or Timber Overlay Flooring System Design Guide Edition 4.0 December 2023), and
  • b) installed in accordance with the Timber Overlay Flooring System Installation Guide Edition 3.0 April 2023, with special reference to the specific requirements for installation in wet areas and with underfloor heating, and
  • c) separated from fuel burning appliances, flues, and chimneys in accordance with NZBC Section CAS/1.
Statement of Building Code Compliance
  • B2 Durability — By analysis and comparison with Verification Method B2/VM1
  • C3 Fire affecting areas beyond the fire source — By testing and comparison with Verification Method C/VM2
  • D1 Access routes — By testing and comparison with Acceptable Solution D1/AS1
  • E3 Internal moisture — By analysis and comparison with Acceptable Solution E3/AS1
  • F2 Hazardous building materials — By testing and comparison with the performance requirements of the New Zealand Building Code clause F2.3.1
Other Performance Attributes
Other Performance Attributes
  • 25 year residential warranty
  • 10 year commercial warranty
  • Low VOC – does not contain any added formaldehyde
  • PEFC® Certified
Documents
Haven Collection Data Sheet

03/25

Forté is a New Zealand-owned and family-run business specialising in refined timber flooring, interior panelling, decking and exterior cladding products for residential and commercial projects.
