• Direct or Cavity fixing
• Horizontal weatherboard for residential use

Prior to the installation of Garrison weatherboards it is important to ensure that:

• The framing complies with the requirements of NZS 3604 timber framed buildings
• The framing is straight and is within tolerances allowed by table 2.1 Tolerances of NZS 3604
• Timber framing moisture content is less than 20%
• Wall underlay is compliant with the requirements set out in table 23 of E2/AS1
• It is recommended that type 304 stainless steel fixings and flashings are used in seaspray and geothermal zones

Garrison weatherboards meet the following provisions of the NZBC:

• Clause B1 Structure
• Clause B2 Durability
• E2 External Moisture
• F2 Hazardous Building Materials

• FSC certified
• Tru-Core treated to H3.1 standard
• Tru-Core meets and exceeds NZS 3640:2003

Warranty and Maintenance

• 15 year warranty
• Timber weatherboards should be cleaned on a regular basis and at least once a year
• Houses situated in a sea spray zone should be checked and could require washing twice to three times a year
