Digital Evolution Vinyl
Description

Belgotex's new digital printed vinyls provide endless possibilities in terms of design, which can not be achieved with conventional printing techniques. With traditional printing techniques there are always a visible repeat in the pattern which can be perceived as artificial, whereas digital can truly imitate the continuous patterns obtainable with modular floors such as LVT and laminate.

  • R10 slip rating
  • 2mm thick with 0.7mm wear layer
  • Class 34 Commercial Very Heavy / Class 43 Industrial Heavy
  • 10 year commercial warranty
Key Features
  • Modern 3D graphical prints
Scope of Use
  • Interior use only
  • Suitable in commercial areas with up to very heavy use
  • Suitable in industrial areas with up to heavy use
  • Suitable in accessways
  • Suitable in water-splash areas and within 1.5m of a sanitary fixing
Limitations on Use
  • Must be installed by a qualified installer
  • Installation to be undertaken to industry best practice guidelines
  • Must be maintained in line with Belgotex's care and maintenance guidelines.
  • Substrate must have 75% or less relative humidity
Statement of Building Code Compliance
  • B2.3.1(c) Alternative Solution, Digital Evolution is manufactured to ISO9001 standard and meets the minimum durability requirement of 5 years
  • C3.4(b) Acceptable Solution, Digital Evolution has been tested against ISO9239-1 standard achieving a CRF of 9.0kW/m2
  • D1.3.3(d) Acceptable Solution, Digital Evolution achieves an R10 slip rating when tested to DIN51130:2014 standard
  • E3.3.3, E3.3.5 Acceptable Solution, Digital Evolution is considered an integrally waterproof sheet material under E3/AS1, 3.1.1(a)
  • F2.3.1 Verification Method, Digital Evolution is FloorScore certified
In-Service History

Belgotex sheet vinyl has been installed in buildings in New Zealand for over 5 years, with most original installations still in service.

Other Performance Attributes
  • 10 year commercial warranty
Documents
BPIR: Commercial Heterogeneous Sheet Vinyl

02/07/2024

Data Sheet

26/04/2024

Fire Test

19/10/2021

Slip Test

07/10/2019

Additional Information

Belgotex are one of New Zealand’s leading flooring distributors, with a comprehensive collection of carpet, vinyl and outdoor flooring solutions
