Bentonite Suction Force Ensures a Long Lasting Waterproofing Solution

Sodium bentonite generates a powerful suction force which can hydrate itself even if no water is added to it by drawing moisture from the soil in the surrounding area. Bentonite is capable of producing a suction force of 650psi — this is enough suction to draw water from even very dry soils.

As the bentonite hydrates, the suction force is reduced to the point where an equilibrium is reached between the suction of the bentonite and the suction of the adjacent soil. The point where Voltex reaches equilibrium is around 100% moisture content. While this may sound high to the layperson, it is worth noting that Voltex is considered fully hydrated at 150-250% depending on the confining pressure. Even if the Voltex loses some of its moisture over time, there is still a suction force present that would allow additional water to be absorbed if it were to become available.

For further information, read over either CETCO's Technical Reference on Wet / Dry Cycling or the Volclay BRANZ Appraisal on the Volclay Voltex product page.

Volclay Swelltite

Allco Waterproofing Solutions

View Product

Volclay Swelltite is a bentonite waterproofing membrane designed for below grade masonry block, split-slab deck and plaza construction.

Swelltite is designed for waterproofing below-grade vertical and horizontal structural surfaces, as well as, above grade split-slab construction used with plaza areas, parking garages and sports stadiums.

Swelltite is excellent for:

Below-grade masonry block walls
Split-slab Plaza Deck Construction
Cut & Cover Tunnels
Masonry Block Foundation Walls
Concrete Foundation Walls
Earth-covered Structures

Installation:

Ready for use and requires no set-up
Does not require torching or priming
It can be applied in all weather conditions to green concrete
Can be installed in temperatures below freezing

In the opinion of BRANZ, the Volclay Waterproofing System if designed, used, installed and maintained in accordance with the statements and conditions of this Appraisal, will meet the following provisions of the NZBC:

Clause B2 DURABILITY: Performance B2.3.1 [a] not less than 50 years. the Volclay Waterproofing System meet this requirement. See Paragraph 14.1.
Clause E2 EXTERNAL MOISTURE: Performance E2.33. the Volclay Waterproofing System meet this requirement. See Paragraphs 16.1 - 16.3.
Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. the Volclay Waterproofing System meet this requirement and will not present a health hazard to people.

BRANZ Appraisal is of an Alternative Solution in terms of New Zealand Building Code compliance.

BRANZ Appraised

Volclay Waterstop RX

Allco Waterproofing Solutions

View Product

Waterstop-RX is an active bentonite / butyl-rubber based waterstop designed to stop water infiltration through cast-in-place concrete construction joints by expanding upon contact with water to form a positive seal against the concrete.

Applications include both vertical and horizontal non-moving concrete construction joints, new to existing concrete construction, irregular surfaces, and around through-wall penetrations, such as plumbing and utility pipes.

Additionally Waterstop-RX can seal around concrete pilings and steel H-piles passing through the slab. Waterstop-RX works in both continuous hydro-static and intermittent hydro-static conditions.

B2 DURABILITY: Performance B2.3.1 (a) not less than 50 years.
E2 EXTERNAL MOISTURE: Performance E2.3.3.
F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. The Volclay Waterproofing System meets this requirement and will not present a health hazard to people.

BRANZ Appraised
