Door Alignment:

• Door misalignment of up to 8mm is corrected

Side Load Release:

• The door can have in excess of 100kg being applied and it will still release instantly when requested

High Security:

• Automatic deadbolting
• 10,000N holding force (1,000kg)
• 10mm thick stainless steel bolt pin

Electronic Convenience:

• Input voltage from 12VDC – 24 VDC
• Less than 50mA standby current
• Reverse polarity and transient protection
• Multiple attempts to lock

Simple Configuration:

• Convert from Fail Safe to Fail Secure by repositioning a single jumper

Dual Monitoring:

• Door and bolt position monitors

Versatile Installation:

• Mortice mount horizontally or vertically, on single acting doors
• Surface mount with the aid of the YD30M accessories, including mounting onto glass

Physical dimensions:

• 160mm L x 30mm W x 51mm D
