Armstrong Metalworks F Plank
Description

Flexibility is key with Metalworks F-Plank, which combines a range of profile and colour options with the ability to transition from ceilings to walls — all with a sophisticated, clean look.

Made from galvanised steel and available in white or grey, or a range of custom colours. To create a Contrasts system, a black Filler Strip is available.  Micro-perforated panel options provide cater for acoustic requirements.

Key Features
  • Acoustic options with micro-perforated panels
  • Available in White (RAL9016), Silver Grey (RAL9005), and custom finishes
  • Three profile widths: 100, 200 and 300mm (nom) including a 20mm reveal
  • Edge Detail: Square with extended flange
  • Galvanized Steel — 0.6mm thick, 8.07kgs/m²
  • Flexible Installation: on the ceiling, on the wall, or create 90º angled or curved ceiling-to-wall transitions
  • Fast and easy installation
  • Durable — washable, scrubbable, impact-resistant, soil-resistant
Scope of Use
  • Flexible Installation:
    • ceiling
    • wall
    • ceiling-to-wall transitions (90º angled or curved)
  • Suitable for:
    • Airports, bus/train stations
    • Atria, lobby/reception areas
    • Educational facilities – lecture theatres, libraries
    • Restaurants
    • Open-plan spaces
Limitations on Use

When specifying or ordering, include the appropriate two letter colour suffix (eg F1030M1WH – for White, F1030M1SG – for Silver Grey)

Microperforated panels feature an unperforated border and include acoustical fleece

Statement of Building Code Compliance

Fire Resistance: Conforms with NZBC. Tested to AS/NZS 3837:1998 – Group 1, AS/NZS 1530.3, ISO 5660 – Group 1 –S

In-Service History
  • NRC 0.7 (perforated panels)
  • Up to 77% light reflectance
Documents
Data Sheet
