SPS Introduces New Innovation in Ceramic Facades

Frontek Panels are the world's only 19mm extruded panels designed for facades. Thanks to the revolutionary production process each piece is manufactured to perfection.

Frontek is unique in ceramic facades as it has the advantage of being one of the lightest, but strongest solutions on the market. With a weight of just 32kg/m² and only 19mm, it is still one of the toughest ceramic facades available today. Increasing the size of the panel does not increase the thickness required, so the weight per m² stays the same no matter what panel size is specified.

Frontek extruded panels are the only thick panels that are rectified on all four sides, therefore offering levels of tolerance unattainable for other materials.

Extruded panels are compact porcelain that allows a wide range of finishes and sizes. The porcelain ensures they have extremely low water absorption, especially compared to natural stone and terracota. It also ensures its cleanability is higher than other similar facades.

The Frontek ventiliated facade system is designed for use with South Pacific Shingles' unique mechanical fixings systems. This includes low cost systems for interior wall systems.

The standard catalogue of textures, polished and printed finishes includes recent metallic and customised designs to meet latest trends.

Frontek — Ceramic Porcelain Facades

The Building Agency

View Product

Frontek facade cladding panels are extruded ceramics in vitrified porcelain that have excellent technical attributes for the cladding of facades: extremely hard, light in comparison to other large format ceramics, highly resistant and long-lasting, with low water absorption and excellent performance against weather and the most demanding environmental conditions.

For use on residential, commercial, and high-rise buildings
Located in any wind zone up to and including 'Extra High' (as classified in NZS3604) or where the building is specifically designed to AS/NZS1170 'Structural Design Actions' up to a maximum design wind pressure differential of 2.5kPa (ULS)
For exposure zones B, C, and D as described in NZS3604
Seismic - lateral racking testing confirm seismic SLS in-plane deflection is within 20 mm

B1 STRUCTURE B1.3.1, B1.3.2, B1.3.3 (a, f, h, j, q), B1.3.4 (a, b, c, d, e) ETA 15/0262 and ETA 15/0916 confirm that the Frontek Ceramic Tiles, when installed, meet the ETAG specification for ventilated wall claddings. These requirements also meet the Building Code requirements in respect of B1 (structure). Lateral racking testing confirm seismic SLS in-plane deflection is within 20 mm. [FacadeLab, 12/2020].
B2 DURABILITY B2.3.1 (b) Stainless steel and aluminium are suitable for use in all corrosion zones. ETA 15/0262 and ETA 15/0916 establishes that the ceramic tiles are not affected by freeze-thaw cycles. Ceramic tiles have a history of use in NZ and are resistant to UV radiation, chemical and biological attack.
C3 FIRE AFFECTING AREAS BEYOND THE FIRE SOURCE C3.5,C3.7 (a) Tested for combustibility in accordance with ISO 1530 by NATA accredited laboratory. Material not deemed combustible [CSIRO Infrastructure Technologies, 29/04/2020]. › Tested in accordance with ISO 5660, by NATA accredited laboratory. Material classified as Group 1 [AWTA Product Testing, 15/11/2017].
E2 EXTERNAL MOISTURE Contributes to E2.3.2 ETA 15/0262 and ETA 15/0916 confirms that Frontek® Ceramic Tiles, when installed, contribute to the management of external moisture. › Tested to AS/NZS 4284 by an IANZ accredited laboratory [FacadeLab, 18/12/2020].
F2 HAZARDOUS BUILDING MATERIALS F2.3.1 Meets EN ISO 14.021, which confirms that the tiles do not contain or emit harmful materials.

Independent Assessment

PASS

Test Results
