DriSpace Brings Compatible Weather Protection and Ventilation Systems to NZ

Recent research shows that internal moisture and condensation in the roof space is a widespread and growing problems across New Zealand. Passive ventilation is a method of allowing continuous airflow into a building above the thermal envelope and minimises internal moisture from the roof cavity and prevents condensation and mould from forming. DriSpace Systems offer comprehensive and easy to follow vented roof and wall systems and allow specifiers, designers and architects to choose the right systems and components in a simple manner.

Download DriSpace Literature on the DriSpace website: www.drispace.co.nz

DriSpace systems combine high vapour permeable DriStud roof and wall underlays, with VENT passive ventilation products and Proctor technical membranes and allow buildings to achieve balanced airflow through both habitable and non-habitable areas. These products are engineered specifically for NZ weather conditions and comply with the NZBC.

DriStud

DriStud is a NZ brand of building products servicing both residential and commercial sectors. DriStud products are engineered for NZ weather conditions and designed to be durable, highly functional and easy to install. The product range includes: wall wrap, window flashing tapes, synthetic roof underlays and foil insulation.

Vent NZ

VENT is a leading New Zealand specialist in the supply of passive ventilation systems and products. The products are structured and specifically tailored to NZ buildings and NZ's extreme climatic conditions. VENT was created as a direct result of the misconception that the ‘Leaky Homes’ disaster that gripped New Zealand was caused solely by external moisture penetration and product failure.

Proctor

Proctor products, whose origin is from the UK in the early 1900’s, specialise in manufacturing construction membranes. Proctor Group Australia has been servicing the Australian and New Zealand building and construction industry with an extensive portfolio of high-performance thermal and acoustic insulation, vapour control layers and self-adhering membranes.

All products are sold through building merchants and roll-formers throughout the country.

DriSpace

DriSpace, is a division of TCL Hunt, whose origins date back to 1937. TCL Hunt has been a leader in the supply of high quality technical materials and equipment to many different industries including the building sector. TCL Hunt has a Quality Management System which has ISO 9001 and ISO14001 certification. With an expert team and the technical resources of their suppliers, TCL Hunt rises to the challenge of providing best practice solutions, with products and services that build and maintain customer loyalty.

DriStud W11 - Fully Synthetic Fire Retardant Premium White Faced Foil Insulation

DriSpace

View Product

DriStud W11 is a Fire Retardant, fully synthetic, vapour, water barrier and a light diffuser insulation product.

DriStud W11 has a premium white face to increase light diffusion and reflection. It is used to line walls and under roofs to give a clean white finish when installed with white facing down or inside.

Where DriStud W11 is used for new construction or in connection with a building consent the work should be undertaken or supervised by a Licensed Building Practioner (LBP).

DriStud W11 has been tested to AS/NZS 4200:2017 and meets all the requirements of the NZBC:

Clauses B2, Durability (B2.3.1[b] 15 years),
E2 External Moisture E2.3.2,
F2 Hazardous Building Materials F2.3.1.

CodeMark

ProctorPassive Wraptite SA

DriSpace

View Product

Protor Passive Wraptite-SA is a self adhering airtight and vapour permeable membrane for wall and roof applications.

Declare LBC Red List Free

Proctor Passive Wraptite SA can be installed on new and existing buildings and it is suitable for roof and wall applications for residential, commercial and high rise buildings.

Proctor Passive Wraptite SA's high vapour permeable peel and stick products used full coverage in pitched roofs and walls allows excellent drying capacity for assemblies wet during construction and from typical in service leaks over the life-time of the building.

Proctor Passive Wraptite SA can be installed over rigid air barrier, replacing tape and flexible underlay. It offers minimal mechanical fixings and provide greater integrity of installation and system.

Multiple substrate compatibility:

Exterior Gypsum Sheathing
Aluminium (painted or mill finish)
OSB
Most rigid insulation
Cast-in place concrete
Rigid vinyl
Pre-painted steel
Galvanised metal
Precast concrete
Steel
Concrete block
Plywood

When specified and installed in accordance with the technical literature, Proctor Passive Wraptite SA will comply with the following provisions of the NZ Building Code;

B1 Structure: B1.3.1, B1.3.2, B1.3.3 (c, h, q), B1.3.4 (a, b, c, d, e)
B2 Durability: B2.3.1 (a), B2.3.2 (a)
C Protection from Fire: C3.4(c)
E2 External Moisture: E2.3.2, E2.3.7 (a, b, c)
F2 Hazardous Building Materials: F2.3.1

CodeMark

ProctorWrap Rainscreen IT

DriSpace

View Product

ProctorWrap Rainscreen with Integrated Tape (RS-IT) is a two layer membrane consisting of a spun bonded polyester layer with a unique functional coating that offers improved resistance against UV and high temperatures up to 120°C.

ProctorWrap RS-IT is suitable for installation in vertical wall constructions behind ventilated facades with regularly spaced open joints no greater than 50mm wide accounting for no more than 30% of total surface area.

The rainscreen façade has to be ventilated according to the façade manufacturers installation instructions but a ventilation gap (min.40mm) is necessary. Long term UV resistance is dependent on the percentage of the cladding that is open, the size of openings, and the width of the cavity. Please contact DriStud Technical team at TCL Hunt Building Products to seek assurances on the suitability of ProctorWrap RS-IT for the particular application.

This product if used in accordance with instructions will meet or contribute to the following provisions of the New Zealand Building Code:

Clause B1 STRUCTURE: Performance B1.3.1, B1.3.2, B1.3.3 (a, c, q), B1.3.4 (a, b, c, d, e)
Clause B2 DURABILITY: PerformanceB2.3.1 (a), B2.3.2 (a)
Clause C3 FIRE AFFECTING AREAS BEYOND THE SOURCE: Performance C3.4(c)
Clause E2 EXTERNAL MOISTURE: Performance E2.3.2, E2.3.7 (a, b, c)
Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1
