Intended applications include: residential housing, walkways and car parking in commercial spaces, perimeter security detection for commercial, institutional and industrial locations.

• Fully waterproof to IP55, this sensor can be located externally in exposed locations
• Due to the low operating temperature minimum and waterproof ratings, SMARTSENSE PRO can also be deployed inside chillers and freezers down to -25°C
• Aiming adjustment is via a ball-joint with inbuilt lock mechanism so it cannot shift in high wind zones
• Features two power entry gaskets for looping, and can be wired from the rear or from below the mounting base if cabling is surface mounted

Installation should be completed by a registered electrician.

PIR sensors detect heat signature movements in comparison to ambient temperature. In locations with higher ambient temperatures the PIR can struggle to identify a temperature difference if the ambient and moving heat signatures are close together. The maximum operating temperature for reliable triggering is considered at 50°C, and minimum ambient temperature for reliable triggering is considered down to -25°C.

SDoC compliance tested to AS/NZS 60669.1:2017 + 60669.2.1:2021, and to AS CISPR 15:2017. Additionally conforms to REACH and RoHs directives.

SIMX Lighting have been supplying PIR sensors to the electrical trade since 1983. Due to this, SIMX knowledge of sensors is unequalled.

The predecessor PIR sensor that the new SMARTSENSE PRO is succeeding has been sold in New Zealand since 2006, with well over 600,000 units installed in both residential and commercial applications.

• Fully waterproof to IP55, this sensor can be located externally in exposed locations
• Constructed of UV stabilised Polycarbonate
• Aiming adjustment is via a ball-joint with inbuilt lock mechanism so it cannot shift in high wind zones
