Equus Chevaline Epistixx Floor Coating
Description

Equus Chevaline Epistixx Flooring is an epoxy flooring coating for use on most interior surfaces that provides an easy to clean, hygienic, medium duty floor finish.
The system includes a two-component waterborne epoxy primer/bodycoat with high adhesion, and a two-component waterborne epoxy topcoat that provides a glossy, fast-curing finish.

With an AsureQuality certification and Clean Room standard ISO 14644 approval, this floor coating is an optimal solution in the food processing and agricultural industries as a medium duty flooring for workshops, sheds, and packhouses. Chevaline Epistixx is ideal for use in a situation where solvent release during application is not desirable, and fast curing is essential.

Key Features
  • 100% NZ made
  • Proven durability with 40+ years in service history
  • Easy to clean and maintain
  • Economical floor coating option
  • Medium duty floor finish
  • Hygienic floor coating, Clean Room standard ISO 14644 approved
  • High adhesion to most surfaces
  • Wide dilution tolerance for application requirements
  • Can be used on contaminated surfaces eg. residual bitumen or paint
Ranges
Flooring
Scope of Use
  • Generally used over new or existing concrete flooring in a variety of residential (eg. garage floors) and commercial areas (eg. dairy factories) as a medium duty interior finish. It is well suited for clean rooms, food processing, and other agricultural and hygiene applications.
  • The system is easy to clean, easy to maintain and provides a smooth or non-slip finish in areas where non-slip is required such as industrial wet floors
  • AsureQuality certified and Clean Room standard ISO 14644 approved, Epistixx is a great solution for the food processing and agricultural industries as a medium duty flooring for workshops, sheds, and packhouses.
  • Chevaline Epistixx can be used for some exterior applications, and in industrial environments by specific design only.
Limitations on Use

Must be used in accordance with the correct specifications and substrates mentioned in this TDS, or in other Equus approved technical documentation. Not suitable as a heavy-duty floor finish. Not suitable for exterior conditions or in areas of with UV exposure except where specifically approved by Equus Industries.

Statement of Building Code Compliance
  • B2 Durability - B2.3.1(c) Chevaline Epistixx Rapid Floor Coating System has a durability of at least 5 years when installed with the correct specification, installation and maintenance.
  • C3 Fire affecting areas beyond the fire source - C3.4 (b) Chevaline Epistixx Rapid Floor Coating System test data together with in-service history of the correctly installed system show that the product limits the probability of fire spreading throughout the building. See BRANZ Fire Test Report FH5525.
  • D1 Access Routes - D1.3.3(d) Chevaline Epistixx Rapid Floor Coating System complies with D1/AS1 on level surfaces, and on sloping surfaces and stairs with the addition of aggregate in the topcoat to create Chevaline Epistixx Rapid NS Floor Coating System.
  • F2 Hazardous building materials - F2.3.1 Chevaline Epistixx Rapid Floor Coating System is a waterborne material and contains no mammalian-toxic substances. Refer to product SDS’s at www.equus.nz
  • G3 Food preparation and prevention of contamination - G3.3.2(a), G3.3.2(b) Chevaline Epistixx Rapid Floor Coating System complies with G3/AS1 in food processing and preparation areas. Refer to AsureQuality Approval.
In-Service History

Over 40 years in service history in New Zealand

Documents
Equus Document Library
Chevaline Colourglaze System and Epistixx Rapid System – FH 5525 Fire Test Report

Equus Industries Ltd provide technical waterproofing, tanking, coating and flooring solutions for architects, engineers, property managers and contractors in the building industry.
