Asona Triton 4
Description

Triton4™ is an economical, mat white ceiling panel designed for exposed grid and tile ceilings to control unwanted noise reverberation.

Key Features
  • Good sound absorption to control reverberation, αw /NRC 0.65
  • Fire Group 1-S
  • Made in NZ for short lead times including replacement parts
  • Product stewardship Renew and Reuse program available
  • Packaging take back and reuse scheme available (NZ only)
  • Durable and dimensionally stable in high humidity
  • Light weight for seismic, very easy to work and trim
  • Mix and matches with other specialist Triton acoustic tiles
  • Low freight and handling costs (250m² per m³)
Categories
Suspended Ceilings
Ranges
Triton
Green Tag Certified
Green Tag Certified
NZ Made
NZ Made
NZ-Owned Business
NZ-Owned Business
Scope of Use

Triton4™ is ideal for use with Rondo Donn DX® exposed grid forgeneral areas requiring good sound absorption, light reflectance and clean white aesthetics at an economical budget.

Limitations on Use

· For interior use only, and not in direct contact with water.

· Not for use with negative air return plenums.

· Maximum humidity/temperature 99% R/H at 45°C.

· No back loading, loads to be independently supported.



Statement of Building Code Compliance

NZ Building Code Compliance:

·  B2 Durability – Clause B2.3.1 (c) (i): Asona ceiling tiles with only normal maintenance will have a minimum durability of at least 5 years when installed in accordance with; manufacturer’s  installation requirements and AS/NZS 2785:2020.

·  C3 Fire – Clause C/AS2 3.4(a): Asona 4 has a Fire Material Group Number 1-S by NZBC verification method C/VM2 Appendix A, tested in accordance with ISO 5660 or ISO 9705.



NZ Building Act

This product is not subject to a warning or ban under Section 26.



In-Service History

New product.

Other Performance Attributes
  • High light reflectance
  • Lightweight
  • Alternative to low cost mineral fibre
  • NZ made
Test Results
Test Results
Documents
Asona Triton 4

24.08
