Allsheet DPM
Description

Allsheet is a multi-layer damp proofing membrane manufactured from virgin resin flexible polyethylene. Allsheet has excellent tear resistance and puncture resistance and is highly resistant to acid and base chemicals.

As a damp proof membrane, Allsheet can be for use in low risk / non-hydrostatic conditions, providing some basic gas-barrier properties. Please note that DPM does not form part of Allco's Waterproofing System and is used solely as a damp-proof membrane.

  • Allsheet 500 (500 micron) is supplied in (flat wound) roll form 2m x 50m
  • Allsheet 300 (300 micron) is supplied in (flat wound) roll form 4m x 25m
Key Features
Property Unit Test method Value
Thickness Mm   0.5
Tensile strength at break MPa ASTM D 6693 25/20
Elongation at break % ASTM D 6693 1000/1000
Tear resistance N ASTM D 1004 35
Puncture resistance N ASTM D 4833 120
Water vapour flow transmission Glm / 24hr ASTM E 96 – E
Scope of Use

As a damp proof membrane, Allsheet can be for use in low risk / non-hydrostatic conditions, providing some basic gas-barrier properties. Please note that DPM does not form part of Allco's Waterproofing System and is used solely as a damp-proof membrane.

Limitations on Use

Important to note that DPM is not waterproofing and it should be solely used as a damp-proof solution.

Allsheet has a minimum life of 50 years under the following conditions:

  • 1. Must be installed as outlined in E2/AS1 10.3.3. Damp Proof Membranes, and must be laid on a properly prepared base as required by NZS3604:2011 & E2/AS1.
  • 2. Free from tear, puncture or damage during installation
  • 3. Storage away from direct sunlight prior to installation
  • 4. Is not left exposed for more than 28 days.
  • 5. No exposure to corrosive or petrochemical agent
  • 6. Installed by or under the supervision of a licensed building practitioner.
  • 7. The concrete remains unbroken
  • 8. The building maintains structural integrity
Statement of Building Code Compliance

Must be installed as outlined in E2/AS1 10.3.3. Damp Proof Membranes, and must be laid on a properly prepared base as required by NZS3604:2011 & E2/AS1.

Documents
Additional Information

Allco Waterproofing Solutions specialise in quality waterproofing products supplying Volclay, Casali, Hydrotech and JM TPO.
