Shake Metal Tile
Description

Metalcraft Roofing produces the Shake Metal Tile profile which is available in both pre-painted and stone chip finishes. These Tiles complemented by a range of flashing and trim options provide a quality finish to any dwelling.

Metal Tiles offer a cost saving solution in comparison with heavier alternative roof tiles, as they require less reinforcing timber in the roof bracing. In addition to the cost saving benefits of a lightweight roof, Metalcraft Lightweight Metal Tiles are also resilient in extreme weather conditions.

Unlike other roofing systems which predominantly rely on the weight of the roof itself to hold the tiles in place, Metalcraft Metal Tiles benefit from their interlocking design and extensive nailing pattern which makes them impenetrable to even gale force winds.


Key Features
  • Defined edge
  • Lightweight, reducing costs associated with reinforced trusses
  • Pressed Colorsteel, and available in stone chip finish
  • Minimum roof pitch 15°
Limitations on Use
  • Minimum roof pitch 15°
Documents
BPIR/PTS

02/2022

Span Tables
Fire Testing Document
CAD/PDF Link
Product Brochure
Colour Range

Metalcraft Roofing are a privately owned building product rollformer and installer with an extensive range of longrun roofing profiles, lightweight metal tiles and rainwater system solutions.
